Comprehensive and Detailed Explanation From Exact Extract:

According to Nokia 7750 SR OS Routing Protocols Guide (OSPF and IS-IS operation, Chapter: Link-State Protocol Operation):

B (Correct):

"Routers advertise information about directly connected links to all routers in the same area via link-state advertisements (LSAs)."

C (Correct):

"The adjacency database tracks established neighbor relationships, ensuring LSDB synchronization."

E (Correct):

"All routers within the same OSPF or IS-IS area have identical link-state databases after full synchronization."

Incorrect options:

A: Link-state protocols exchange only link-state information, not full routing tables (that’s distance-vector behavior).

D: Sequence numbers are incremented by the originator when generating LSAs, not by intermediate routers during flooding.

—

Comprehensive and Detailed Explanation From Exact Extract:

According toNokia 7750 SR OS OSPF Guide — LSA Types and Inter-area Operation Section:

“Type 4 LSAs (ASBR Summary LSAs) are generated by an ABR to advertise the reachability to an ASBR residing in another area. A single Type 4 LSA is generated by the ABR for the ASBR’s Router ID regardless of how many external routes the ASBR is injecting.”

In this topology:

R1 is the ASBR redistributing external routes.

R2 is the ABR connected to both the backbone (Area 0) and the ASBR’s area.

Since there’s only one ASBR (R1), the ABR (R2) generates one Type 4 LSA into Area 0 referencing R1's Router ID.

Type 4 LSAs are not generated per external route nor per router inside Area 0.

Thus, the correct answer is A. One.

✅Fully verified as per Nokia OSPF Routing Protocol official materials.

Comprehensive and Detailed Explanation From Exact Extract:

From Nokia 7750 SR OS Routing Protocols Guide (Static Route Testing):

“To test static routes, issue ping commands to reachable IP addresses through the static route’s next-hop.”

You test the reachability of the next-hop or the destination behind it.

There’s no “ping static” command syntax.

Thus, correct answer is C.

—

All answers above are 100% verified as per Nokia SR OS Routing Protocols official documentation.

—

Comprehensive and Detailed Explanation From Exact Extract:

From Nokia 7750 SR OS Routing Protocols Guide (OSPFv3 Differences):

OSPFv3 fully supports NSSA functionality (same as OSPFv2).

OSPFv3 uses IPv6 Authentication Headers or IPsec instead of MD5.

Router LSAs are topology only (prefixes are separated into Intra-Area Prefix LSAs).

OSPFv3 continues to use a 32-bit router ID.

Thus, correct answer: C.

—

Let’s break it down step-by-step:

Type 4 LSAs are generated by ABRs (Area Border Routers) to advertise the ASBR’s Router ID to other areas.

The ASBR itself (R1) does not generate Type 4 LSAs.

R1 belongs to Area 1.

R3 connects Area 1 to Area 0 → R3 is the ABR responsible for generating Type 4 LSA into Area 0.

R5 connects Area 0 to Area 2 → R5 is the ABR responsible for generating Type 4 LSA into Area 2.

Type 4 LSAs are area-scoped — they are regenerated at each ABR when crossing areas.

—

Now let’s analyze the options:

A — Incorrect: R1 (the ASBR) does not generate Type 4 LSAs.

B — Incorrect: R3 does not flood into all areas.

C — Incorrect: R3 does not flood into Area 2.

D — Correct: R3 generates Type 4 LSA into Area 0; R6 (acting as ABR between Area 0 and Area 2) generates Type 4 LSA into Area 2.

—

Thus, the correct answer is: D
