DES-1D12 EMC Specialist - Technology Architect Midrange Storage Solutions Exam Free Practice Exam Questions (2025 Updated)

Capacity forecasting requires the installation of a special license to display capacity forecasting metrics. If the license is not installed, then the forecasting metrics will not be displayed.

Dell is providing native support of NVMe to the midrange of the market, which improves performance.

An administrator can use a user quota to limit the amount of storage that the user consumes on a Dell PowerStore system. A user quota is a limit that is set on the quota tree, which is a hierarchical structure that organizes storage resources and sets limits on how much storage can be used at each level. The user quota is applied to a specific user or group of users and limits the amount of storage that can be consumed by that user or group of users.

https://www.delltechnologies.com/resources/en-us/asset/data-sheets/products/storage/h18143-dell-emc-powerstore-family-spec-sheet.pdf

"SCOS 7.3, Distributed Sparing: eliminates the need for dedicated spares by giving customers the option to distribute sparing capacity across all drives in the array."

FAST Cache is an intelligent caching technology that optimizes data access for OLTP workloads by tracking and promoting data at the granularity of 8KB blocks. It uses a combination of flash memory and DRAM to store frequently accessed data, allowing the system to quickly access the most frequently used data, reducing latency and improving overall performance.

"Whether gathering information or designing a system, it is important to understand two commonly used terms: Latency and queue depth"

The base enclosure is an all-NVMe platform, capable of supporting NVMe SSD, NVMe SCM, and NVMe NVRAM drives. You can populate slots 0 through 20 with NVMe SSD or NVMe SCM drives. Slots 21 through 24 are reserved for NVMe NVRAM drives which serve as additional system write caching. PowerStore 1000 and PowerStore 3000 models contain two NVMe NVRAM drives in slots 23 and 24.

https://www.dell.com/support/manuals/en-us/powerstore-5000/pwrstr-protect-data/protection-policies?guid=guid-c8ba3ba4-6374-4285-9727-900343f64ee2 &lang=en-us#:~:text=Each%20protection%20policy%20can%20only,up%20to%20four%20snapshot%20rules.

The maximum number of SAS buses per SP for a Dell Unity XT 480F without an additional SAS I/O module is 2. Each Dell Unity XT 480F has 2 Service Processors (SPs) and each SP has 2 SAS buses, for a total of 2 SAS buses per SP. SAS buses are used to connect the storage drives to the SPs and to the storage array. Each bus can support multiple drives and provide high-speed data transfer between the drives and the SPs.

https://www.dell.com/support/manuals/en-us/storage-sc7020/sc7020-om/sc7020-series-storage-system-back-panel-view?guid=guid-ba3314b9-ddaf-4413-8a25-4bb66c2d421b &lang=en-us

Here we clearly have Each storage controller contains:[...] Expansion slots for I/O cards: Slots for optional front-end connectivity – Fibre Channel and iSCSI I/O cards Slots for optional back-end connectivity – SAS I/O cards [...] SCv3000, SCv3000 and SC5020 owner manual say: One expansion slot for a front-end I/O card:

https://www.delltechnologies.com/de-at/collaterals/unauth/technical-guides-support-information/services/h17356-storage-config-sap-hana-tdi-sc-vg.pdf

When a Windows client uses the SMB protocol to access a multiprotocol file system from a Dell Unity XT NAS server, the SID (Security Identifier) of the Windows user is mapped to a UID (User Identifier) on the UNIX file system. If no mapping is found in the local group database, the domain controller is checked to see if the SID is present there. The domain controller can provide the information needed to map the SID to the corresponding UID on the file system, allowing the Windows user to access the files. If the SID is not present in the domain controller, the Windows user's access would be removed.

A migration import allows data to be transferred from an existing storage platform to a Dell PowerStore cluster. The platforms that support migration import to a Dell PowerStore cluster include Unity, VNX2, Dell EqualLogic PS series and Dell Compellent SC Series. These platforms are EMC storage systems, which are now owned by Dell Technologies.

The maximum number of data drives that can be put in to a Dell PowerStore 1000T base enclosure is 21. The Dell PowerStore 1000T has a 2U form factor, and it supports a maximum of 21 drives in the base enclosure. The drives can be either SAS or NVMe, and it's important to keep in mind that the maximum capacity of the system depends on the type of drives that are used. It's important to note that the PowerStore 1000T supports up to 2 expansion shelves that can hold an additional 21 drives each, for a maximum of 63 drives in total. Also, the PowerStore 1000T supports up to 4 NVRAM modules that are used to cache metadata and improve performance.
