Fortinet FCP_FSA_AD-5.0 Practice Test Questions Answers

From the High Availability and Management lesson, the Study Guide states:

" You must configure the HA group name, password, and the virtual IP only on the primary node. After you configure those, you can add the secondary node to the group using the commands shown on this slide. "

The hc-slave command (shown as hc-worker for secondary) requires pointing to the Primary Node ' s HA interface IP , not the cluster virtual IP or the primary node ' s port1.

From the exhibit:

Primary Node port4 (HA interface) = 10.50.1.30

Secondary Node port4 = 10.50.1.40

Primary Node port1 = 10.25.1.30

Cluster Virtual IP = 10.25.1.50

The secondary node must connect to the Primary Node ' s dedicated HA communication port (port4 = 10.50.1.30) to join the cluster, making Option B the correct answer.

The Study Guide states that in an HA cluster, “As well as normal scanning duties, the primary node also manages the cluster, distributes jobs, and gathers the verdicts.” It also says that “The worker nodes provide load balancing. The primary node distributes scan jobs to the worker nodes.”

From those official statements, the primary node is not just a coordinator. It also performs normal scanning duties itself, while distributing scan jobs across worker nodes for load balancing. That rules out A, because the secondary node is for failover, not normal job distribution. It rules out C, because the primary is not restricted to itself only. It also rules out D, because the primary can still perform scanning duties and is not limited to sending all jobs only to workers. Therefore, when the primary receives MTA jobs, the correct behavior is that it distributes the MTA jobs to itself or to worker nodes .

From the Scanning and Rating Components lesson, the Study Guide explicitly states:

" VM images are downloaded from FortiGuard, using port1. So, you must ensure FortiSandbox has a default route and internet connectivity for port1. "

The exhibit confirms this — the test-network output shows:

System DNS resolve: Failed for both bing.com and fsavm.fortinet.net

fsavm.fortinet.net is the FortiGuard VM image download server

This DNS failure on the system side (port1) confirms there is no internet connectivity on port1 , preventing VM image downloads. Note that port3 internet shows " Warning: VM to access internet: Disabled " — but port3 is only for VM sandboxing traffic, not for downloading VM images.

From the Deployment and System Settings lesson, the Study Guide states:

" Other ports, with the exception of port3, can also be configured as management ports from CLI. "

" You can set additional ports as management port using the CLI command shown on this slide. "

From the Lab Guide (Exercise 4 - Using Inline Scanning) :

" FortiGate and FortiSandbox communicate through port 4443. Management or API ports grant access through port 4443. "

" Enter the following command to enable API access on port2: set api-port port2 "

Ports that are designated as either administration interfaces or API interfaces cannot be selected for 802.3ad aggregate bonding because:

Option A — Port 4 configured as an administration interface is reserved for management traffic and cannot be repurposed for link aggregation

Option C — Port 4 configured as an API interface is dedicated for API communication (port 4443) and is similarly restricted from being used in aggregate bonding configurations

Port 4 in the Lab Guide is specifically referenced as the HA communication and management port, confirming these restrictions apply when special roles are assigned to interfaces.

From the FortiClient EMS Integration lesson, the Study Guide explicitly states:

" It is always a good idea to place the files that are submitted by FortiClient, high on the Job Queue Priority since these are files that end users need immediate access to. In most cases, end users might not be willing to wait for a long time to access these files and placing the FortiClient submitted files high on the Job Queue Priority ensures that these files receive high priority for scanning from FortiSandbox. "

Looking at the exhibit, the Job Priority Configuration shows:

Positions 1-4: On-Demand inputs (highest priority)

Position 5: FortiGate InlineBlock

Positions 6-11: Other sources including FortiWeb, File RPC, Device, FortiClient

As a best practice, FortiClient should rank after On-Demand (positions 1-4) but before FortiGate inputs — since end users need immediate file access, FortiClient submissions should be near the top but On-Demand scanning takes highest precedence.
