HPE2-K45 HP Using HPE SimpliVity Free Practice Exam Questions (2025 Updated)

 The difference between crash consistent and application consistent cloning methods is that the application consistent method ensures that the cloned virtual machine is in a consistent state with respect to the application and database, while the crash consistent method does not guarantee that1. The application consistent method uses the VMware snapshot or the Microsoft Volume Shadow Copy Service (VSS) to quiesce the application and flush the pending I/O operations to the disk before creating the clone, which prevents data corruption or loss2. The crash consistent method does not quiesce the application or flush the pending I/O operations, and creates the clone as if the virtual machine had crashed, which may result in data inconsistency or recovery issues3. The application consistent method is recommended for virtual machines that run database applications, such as SQL Server or Oracle, while the crash consistent method is suitable for virtual machines that run non-database applications, such as web servers or file servers4. The application consistent method is not available only for Linux operating systems (option D), as it also supports Windows Server operating systems that have VMware Tools or VSS installed5. The crash consistent method should not be used only for the virtual machines with Fault Tolerance enabled (option C), as it can be used for any virtual machine that does not require application consistency. Both methods are not the same,and the speed of cloning is not the only difference (option B), as they have different implications for the data integrity and availability of the cloned virtual machine. References:

1: Using HPE SimpliVity Official Certification Study Guide (HPE2-K45), HPE Press, 2019, p. 28.

2: Clone a virtual machine - techhub.hpe.com, HPE, 2021, 3.

3: HPE SimpliVity OmniStack Interoperability Guide 4.2.0, HPE, 2021, p. 8.

4: Using HPE SimpliVity Official Certification Study Guide (HPE2-K45), HPE Press, 2019, p. 29.

5: HPE SimpliVity OmniStack Interoperability Guide 4.2.0, HPE, 2021, p. 9.

[6]: Using HPE SimpliVity Official Certification Study Guide (HPE2-K45), HPE Press, 2019, p. 28.

[7]: Clone a virtual machine - techhub.hpe.com, HPE, 2021, 3.

The best way to migrate virtual machines from the existing infrastructure to HPE SimpliVity is to share HPE SimpliVity datastores with standard ESXi hosts, and migrate the virtual machines using VMware vSphere® Storage vMotion®1. This method allows the virtual machines to be moved to the HPE SimpliVity datastores without any downtime or impact on the performance. The HPE SimpliVity datastores are automatically created and managed by the HPE SimpliVity Virtual Controller, and they can be shared with any ESXi host that is in the same vCenter Server® as the HPE SimpliVity cluster2. Connecting VMFS datastores holding the virtual machine files to HPE SimpliVity nodes, and migrating the virtual machines (option A) is not a supported method, as the HPE SimpliVity nodes do not have direct access to the VMFS datastores, and they can only use the HPE SimpliVity datastores3. Mapping VMFS datastores holding the virtual machine files as an RDM to HPE SimpliVity nodes, and migrating the virtual machines (option C) is not a supported method, as the HPE SimpliVity nodes do not support RDM devices, and they can only use the HPE SimpliVity datastores4. Adding ESXi system to the HPE SimpliVity cluster, and migrating the virtual machines to HPE SimpliVity datastores (option D) is not a recommended method, as it requires the ESXi system to be converted to an HPE SimpliVity node, which involves installing the HPE OmniStack software and the HPE SimpliVity Virtual Controller, and reconfiguring the network settings. This method may cause downtime and data loss, and it is only advised for specific scenarios, such as replacing a failed node or expanding the cluster. References:

1: Using HPE SimpliVity Official Certification Study Guide (HPE2-K45), HPE Press, 2019, p. 29.

2: HPE SimpliVity OmniStack Interoperability Guide 4.2.0, HPE, 2021, p. 8.

3: HPE SimpliVity 380 Gen10 Node Data sheet, HPE, 2019, p. 5.

4: HPE SimpliVity OmniStack Interoperability Guide 4.2.0, HPE, 2021, p. 9.

[5]: HPE SimpliVity 380 Gen10 Node Installation and Startup Service, HPE, 2019, p. 3.

You can apply a backup policy at the datastore level, as this is the level at which HPE SimpliVity manages the virtual machines and their backups1. A backup policy consists of one or more rules that specify the destination, frequency, and retention of the backups. You can assign a backup policy to a datastore, and all the virtual machines in that datastore will inherit the backup policy. You can also override the backup policy for individual virtual machines, if needed2. Applying a backup policy at the cluster level (option A), the datacenter level (option B), or the vCenter Server level (option C) is not possible, as these are not the levels at which HPE SimpliVity manages the virtual machines and their backups. These levels are used for organizing and managing the ESXi hosts and the HPE SimpliVity nodes, but not for applying backup policies. References:

1: Using HPE SimpliVity Official Certification Study Guide (HPE2-K45), HPE Press, 2019, p. 28.

2: HPE SimpliVity OmniStack Interoperability Guide 4.2.0, HPE, 2021, p. 8.

HPE SimpliVity provides storage HA by creating two copies of each virtual machine data across different nodes in a cluster. This ensures that the virtual machines can continue to run even if one node fails. However, this also consumes twice the storage capacity for each virtual machine. For development virtual machines that do not require storage HA, the customer can save storage capacity by creating a single-replica datastore for these virtual machines. A single-replica datastore is a datastore that has only one copy of the virtual machine data on one node. This reduces the storage consumption by 50%, but also increases the risk of data loss and unavailability in case of node failure. Therefore, the customer should carefully weigh the trade-offs between storage efficiency and data protection when using a single-replica datastore. References: HPE SimpliVity Data Virtualization Platform; HPE SimpliVity User Guide

 HPE Storence Management Console is a web-based management interface for HPE StoreOnce Systems, which are backup appliances that provide deduplication and replication capabilities. One of the features that can be configured using HPE Storence Management Console is the Catalyst store, which is a logical container for backup data that supports Catalyst protocol. Catalyst protocol is a proprietary protocol that enables source-side deduplication, low-bandwidth replication, and direct backup from application servers. Backup policy, storage policy, and deduplication ratio are not specific to HPE Storence Management Console, and can be configured using other tools or interfaces. References: HPE StoreOnce system software, section “Software Details”. The StoreOnce System Management Console, section “The StoreOnce System GUI and CLI together make up the Management Console”. HPE StoreOnce Catalyst User Guide, section “Introduction to HPE StoreOnce Catalyst”.

 According to the HPE SimpliVity 325 Gen10 QuickSpecs1, this model supports up to one NVIDIA Tesla T4 GPU accelerator. According to the HPE SimpliVity 380 Gen10 G Node QuickSpecs2, this model supports up to two NVIDIA Tesla T4 GPU accelerators. Therefore, these two models meet the customer needs for HPE SimpliVity nodes that support NVIDIA Tesla T4 GPUs.

The other models do not support NVIDIA Tesla T4 GPUs. According to the HPE SimpliVity 380 Gen10 QuickSpecs3, this model supports NVIDIA Tesla M10 and P40 GPUs, butnot T4 GPUs. According to the HPE SimpliVity 2600 QuickSpecs4, this model does not support any GPU accelerators. According to the HPE SimpliVity 380 Gen10 SFFH QuickSpecs, this model supports NVIDIA Tesla V100 and P100 GPUs, but not T4 GPUs. References:

1: HPE SimpliVity 325 Gen10 QuickSpecs, https://h20195.www2.hpe.com/v2/getdocument.aspx?docname=a00073576enw

2: HPE SimpliVity 380 Gen10 G Node QuickSpecs, https://h20195.www2.hpe.com/v2/getdocument.aspx?docname=a00073577enw

3: HPE SimpliVity 380 Gen10 QuickSpecs, https://h20195.www2.hpe.com/v2/getdocument.aspx?docname=a00026086enw

4: HPE SimpliVity 2600 QuickSpecs, https://h20195.www2.hpe.com/v2/getdocument.aspx?docname=a00026087enw

: HPE SimpliVity 380 Gen10 SFFH QuickSpecs, https://h20195.www2.hpe.com/v2/getdocument.aspx?docname=a00026088enw

To use this option, you need to select the backup from which you want to restore the files, then click Backup Actions > Restore Files. You will be prompted to enter the following information:

The name of the virtual machine where you want to restore the files

The path of the folder where you want to restore the files

The path of the folder that you want to restore from the backup

The credentials of the virtual machine where you want to restore the files

After you enter the required information, click OK to start the restore process3.

HPE SimpliVity Hyperconverged Infrastructure for VMware vSphere 3.7.10 Administration Guide, page 97

HPE SimpliVity Hyperconverged Infrastructure for VMware vSphere 3.7.10 Best Practices Guide, page 20

Restore files from a backup - techhub.hpe.com

 HPE Reference Architectures for HPE SimpliVity provide validated configuration for a specific workload, such as VMware Horizon, SAP HANA, Microsoft SQL Server, and others. HPE Reference Architectures are designed to reduce the complexities of planning, designing, and implementing infrastructure across a variety of workloads and platforms. They document fully tested and optimized configurations that leverage HPE SimpliVity’s hyperconverged infrastructure and data services. HPE Reference Architectures for HPE SimpliVity do not provide solution pricing and possible discounts, as these may vary depending on the customer’s needs and preferences. They do not provide recommended hardware configuration in ne Config Advanced (CA) format, as this is a tool for configuring HPE products and solutions, not areference architecture. They do not provide comparison with equivalent competitor offerings, as this is not the purpose of a reference architecture. References: Reference Architectures for HPE Systems and Solutions, section “Overview”. HPE Reference Architecture for VMware Horizon on HPE SimpliVity 380 Gen10, section “Abstract”. HPE Reference Architecture for SAP HANA 2.0 on HPE SimpliVity 380, section “Abstract”. HPE Reference Architecture for Microsoft SQL Server 2017 on HPE SimpliVity 380, section “Abstract”.

According to the HPE SimpliVity Administration Guide1, the file level restore option allows you to recover individual files or folders from a backup of a virtual machine. Thisoption is useful when you need to restore a specific file that was accidentally deleted or corrupted, without affecting the rest of the virtual machine. The file level restore option supports both Windows and Linux based virtual machines, and can be performed using the HPE SimpliVity plugin in the vSphere Web Client. The file level restore option creates a temporary virtual machine from the backup, mounts the virtual disks, and copies the selected files or folders to a destination of your choice. The temporary virtual machine is then deleted automatically.

The other options are not suitable for recovering a single file from a Linux based virtual machine. Restoring a virtual machine from the backup would overwrite the entire virtual machine with the backup data, which may not be desirable or necessary. Moving a virtual machine from DR site to the primary site would not help if the file was deleted from both sites. Reverting to the SimpliVity snapshot would also overwrite the entire virtual machine with the snapshot data, which may not be the latest or the most relevant version. References:

1: HPE SimpliVity Administration Guide, https://support.hpe.com/hpesc/public/docDisplay?docId=sf000062138en_us &docLocale=en_US, page 76-78

The Intelligent Workload Optimizer is a feature of HPE SimpliVity that automatically balances the virtual machine workloads across the nodes in a cluster, based on the CPU, memory, and storage utilization1. This feature helps to improve the performance and efficiency of the cluster, and to avoid hotspots and bottlenecks. The Intelligent Workload Optimizer can be configured to run periodically or on demand, and it can also take into account the affinity and anti-affinity rules for the virtual machines2. The Resource Balancer (option A) is a feature of HPE SimpliVity that automatically balances the storage capacity across the nodes in a cluster, based on the free space and deduplication ratio3. This feature helps to optimize the storage utilization and availability of the cluster, and to avoid capacity issues and data loss. The Resource Balancer does not balance the virtual machine workloads or the I/O traffic. The Management Virtual Appliance (option B) is a component of HPE SimpliVity that provides the management interface and functionality for the cluster, such as backup, restore, clone, move, and federation operations4. The Management Virtual Appliance does not balance the virtual machine workloads or the I/O traffic. The Arbiter (option C) is a component of HPE SimpliVity that provides the quorum service for the cluster, ensuring data consistency and availability in the event of a node or site failure5. The Arbiter does not balance the virtual machine workloads or the I/O traffic. References:

1: Using HPE SimpliVity Official Certification Study Guide (HPE2-K45), HPE Press, 2019, p. 83.

2: HPE SimpliVity 380 Gen10 Node Data sheet, HPE, 2019, p. 4.

3: Using HPE SimpliVity Official Certification Study Guide (HPE2-K45), HPE Press, 2019, p. 84.

4: Using HPE SimpliVity Official Certification Study Guide (HPE2-K45), HPE Press, 2019, p. 81.

5: Using HPE SimpliVity Official Certification Study Guide (HPE2-K45), HPE Press, 2019, p. 82.

HPE SimpliVity 380 Ge10G is a hyperconverged solution that combines compute, storage, and networking in a 2U form factor. It supports up to two NVIDIA GPU accelerators per node, which can enhance the performance and user experience of VDI applications. It also offers high availability, data efficiency, and built-in data protection and disaster recovery. It supports VMware vSphere and Microsoft Hyper-V hypervisors, and integrates with HPE InfoSight for AI-driven operations and insights. References: HPE SimpliVity 380 Gen10; Technical Positioning of HPE SimpliVity for VDI solutions
