HPE7-J02 HP Advanced HPE Storage Integrator Solutions Written Exam Free Practice Exam Questions (2025 Updated)

Detailed Explanation:

Rationale for Correct Answer:

HPE SimpliVity RapidDR simplifies and automates DR failover processes, but execution requires an authorized operator to trigger a pre-configured recovery plan. This balances automation with compliance and security requirements (important for healthcare). It does not guarantee zero RTO, but it does minimize RTO through automation.

Distractors:

A: RTO of 0 is not possible; RapidDR reduces but does not eliminate recovery time.

B: Domain admin credentials for re-IP are not required; automation handles reconfiguration.

C: Auto-commit/rollback require administrator validation; no “silent” automation is allowed for compliance.

Key Concept: RapidDR = automation of failover/failback but requires authorized trigger.

Detailed Explanation:

Rationale for Correct Answer:

In Alletra 6000 Peer Persistence environments, operations like resizing Peer Persistence volumes must be performed via the HPE Data Services Cloud Console (DSCC), which manages volume collections and replication consistency groups. Attempting to grow the upstream volume locally will fail because the changes need to propagate across both sites consistently.

Distractors:

A/B: Removing upstream or downstream volumes would break replication and is not required.

D: Expanding in VMware only extends the VMFS datastore, not the underlying replicated volume.

Key Concept: Peer Persistence volume resizing is done in DSCC, not local web GUI.

Detailed Explanation:

Rationale for Correct Answer:

HPE Alletra with InfoSight provides end-to-end visibility from infrastructure through to virtual machines and applications. It offers prescriptive, AI-driven recommendations to simplify management — a key differentiator for startups with small IT staff. Pure arrays do not offer the same level of integrated, cross-stack predictive analytics.

Distractors:

B: “ActiveWorkload” is not an HPE feature — HPE uses Peer Persistence for stretch clusters.

C: Garbage collection is managed automatically in HPE arrays; disabling it is not supported.

D: Data tiering is not natively provided as “software-only” — HPE uses GreenLake and Alletra services.

Key Concept: InfoSight = predictive analytics and app-to-infra visibility differentiator.

Detailed Explanation:

Rationale for Correct Answer:

FC-FC routing (also known as Fibre Channel Routing / LSANs on B-Series switches) allows replication between separate SAN fabrics without merging them. This supports disaster recovery scenarios while preserving fabric isolation, exactly matching the bank’s requirement.

Distractors:

A: FCIP tunnels extend Fibre Channel over IP networks, but this typically merges SAN domains.

C: NPIV (N_Port ID Virtualization) allows multiple virtual WWNs per port, not cross-fabric replication.

D: Fabric partitioning is zoning and segmentation within a single fabric, not between independent fabrics.

Key Concept: FC-FC routing on Brocade (B-Series) for SAN isolation with replication.

Detailed Explanation:

Rationale for Correct Answer:

HPE NinjaSTARS (Storage Assessment and Right Sizing) is the dedicated HPE tool for sizing and configuring StoreOnce backup appliances. It evaluates backup datasets, retention policies, deduplication ratios, and replication to recommend the right StoreOnce model and configuration.

Distractors:

A (CloudPhysics): Used for virtual infrastructure and block storage assessments, not backup target sizing.

C (Ninja Online): General sizing tool, not specific for StoreOnce.

D (OCA): Used for quoting/configuration, but sizing requires NinjaSTARS first.

Key Concept: HPE NinjaSTARS is the StoreOnce sizing tool.

Detailed Explanation:

Rationale for Correct Answer:

HPE GreenLake for Containers delivers an enterprise-grade Kubernetes platform, leveraging open-source Kubernetes but with simplified lifecycle management, monitoring, and integration with HPE infrastructure. It provides full support for containerized workloads, whether cloud-native or modernized traditional applications.

Distractors:

A: Incorrect — not about legacy virtualization.

B: Incorrect — microservices are supported; orchestration is Kubernetes-native.

D: Incorrect — it supports both cloud-native and modernized workloads.

Key Concept: GreenLake for Containers = Kubernetes with simplified enterprise management.

Detailed Explanation:

Rationale for Correct Answer:

The exhibit shows a system delivering ~2.3 GB/s sequential read. For large-block sequential workloads, aggregate host link bandwidth (number × speed of front-end ports) is the primary limiter. Increasing the count of 10/25 Gb iSCSI NICs adds parallel lanes, raising sustained read GB/s to the hosts. This is a recommended first step in HPE sizing before changing protocols.

Analysis of Incorrect Options (Distractors):

A: Adding an expansion shelf increases capacity, not front-end bandwidth.

C: Moving to 32 Gb FC can help, but simply adding more existing 10/25 Gb ports achieves the same goal without a protocol/adapter change and is the straightforward, supported scale-out path.

D: SCM (Storage Class Memory) targets latency/IOPS; it doesn’t materially lift sequential GB/s if the link budget is the bottleneck.

Key Concept: Scale front-end connectivity to increase sequential throughput; capacity or media class changes won’t fix a link-limited system.

Detailed Explanation:

Rationale for Correct Answer:

HPE CloudPhysics provides comprehensive environment assessment and competitive sizing for virtualized environments (VMware, Hyper-V, etc.). The CloudPhysics collector (available as a .vhdx for Hyper-V) is deployed into the cluster to gather metrics on CPU, memory, storage IOPS/latency, and utilization trends. These analytics feed into the sizing of HPE storage solutions.

Distractors:

B: InfoSight sizing tools work with HPE systems, not competitive 3rd-party storage like Pure.

C: SAF is a manual assessment requiring email submission and is not the correct modern method for this case.

D: NinjaProtected applies to backup analysis, not production Hyper-V cluster sizing.

Key Concept: CloudPhysics.vhdx collector for Hyper-V sizing with 3rd-party infrastructure.

Detailed Explanation:

Rationale for Correct Answer:

A Capital Lease (also known as a finance lease) spreads costs over time like OpEx, while giving the customer the ability to own the equipment at the end of the lease term. This matches the desire for predictable payments, eventual ownership, and full control.

Distractors:

A (Consumption model): GreenLake provides OpEx flexibility but does not lead to ownership.

B (Operating lease): Pure rental; equipment must be returned, no ownership.

C (Capital purchase): Requires large upfront payment, which the customer wants to avoid.

Key Concept: Capital Lease = predictable payments + ownership path.

Detailed Explanation:

Rationale for Correct Answer:

HPE GreenLake for File Storage (powered by VAST Data) delivers scale-out NAS capabilities with native data protection, snapshots, and disaster recovery integration. It is designed for enterprises that need both scalability and integrated protection in a single consumption or CapEx model.

Distractors:

A (Qumulo): Excellent scale-out file, but lacks deep HPE ecosystem integration.

B (Scality): Primarily focused on object storage, not file workloads.

D (Cohesity): Strong in backup and secondary storage, but not primary enterprise file services.

Key Concept: HPE GreenLake for File Storage = enterprise-grade file storage + integrated protection.

Detailed Explanation:

Rationale for Correct Answer:

In B-Series (Brocade) SAN switches, trunking requires that all ports in a trunk group belong to the same port group (same ASIC) and run at the same speed. This ensures frame ordering and load balancing across ISLs.

Distractors:

A: Incorrect — cable length differences must be minimal, but not stated in meters like this.

C: Incorrect — speeds must match across all trunked ports.

D: Trunking requires a license on some Brocade models; not always enabled by default.

Key Concept: Port trunking requires same port group and same speed.

Detailed Explanation:

Rationale for Correct Answer:

Zerto Extended Journal allows retention up to one year by integrating with secondary storage like HPE StoreOnce. Short-term journals (seconds to days) reside on primary replication storage, while long-term copies (weeks/months/years) are offloaded to StoreOnce for cost-efficient retention.

Distractors:

A: No separate license is required — it is a standard Zerto feature when integrated.

C: Extended Journals can be sourced from production or target, depending on setup; not “always” target.

D: Incorrect — Zerto supports >30 days retention with Extended Journal.

Key Concept: Zerto + HPE StoreOnce for long-term DR retention.
