The solution is correct because making sure that the SSH server is enabled is a minimum requirement for setting up communications between the switch and NetEdit. NetEdit uses SSH to establish a secure connection to the switch and execute commands on it. Therefore, making sure that the SSH server is enabled is necessary for setting up communications between the switch and NetEdit.

Deploying Aruba 83xx switches as core switches for very large three-tier data center networks is how you should position switches in the ArubaOS-CX portfolio for data center networks. The Aruba 83xx switches are designed for data center spine or core roles, and they provide high performance, scalability, and resiliency. They can support very large three-tier data center networks with up to 512 leaf switches using VSX2.

To reduce the amount of traffic sent over the ISL between Switch-1 and Switch-2, enable active forwarding on LAG 100 on both Switch-1 and Switch-2 is a correct explanation of how to control how core-to-access traffic is forwarded. Switch-1, Switch-2, and the router run OSPF on LAG 100, which is a Layer 3 LAG. Active forwarding is a feature that allows a switch to select one link as active and one link as standby for each direction of traffic in a LAG. Enabling active forwarding on LAG 100 on both Switch-1 and Switch-2 would reduce the amount of traffic sent over the ISL by sending traffic over only one link instead of both1.

The exhibit shows a network topology where Switch-1 and Switch-2 are part of a Virtual Switching Extension (VSX) fabric, and the router runs OSPF on LAG 100, which is a Layer 3 LAG. The question asks how to control how core-to-access traffic is forwarded, which means how the router chooses between the two links to Switch-1 and Switch-2. To force the router to use both links, ensuring that active gateway is enabled on LAG 100 on both Switch-1 and Switch-2 is not the correct solution. Active gateway is a feature that allows both VSX members to act as the default gateway for downstream devices, using a common virtual MAC address. Active gateway does not affect how upstream devices, such as the router, forward traffic to the VSX members1. To force the router to use both links, the correct solution is to configure equal-cost multi-path (ECMP) in OSPF on the router. ECMP is a feature that allows a router to load balance traffic across multiple paths with the same cost. ECMP can be configured using the maximum-paths command and specifying how many equal-cost paths the router should use2. Therefore, this does not correctly explain how to control how core-to-access traffic is forwarded.

A frame with destination MAC address, 00:50:56:15:16:28, arrives with a VLAN 10 tag on 1/1/1 on Switch-1. Switch-1 encapsulates the frame with VXLAN and an IP header destined to 192.168.1.2 is a correct explanation of how the switch handles the traffic. Switch-1, Switch-2, and Switch-3 are ArubaOS-CX switches that use VXLAN and EVPN to provide Layer 2 extension over Layer 3 networks. VXLAN is a feature that uses UDP encapsulation to tunnel Layer 2 frames over Layer 3 networks using VNIs. EVPN is a feature that uses BGP to advertise MAC and IP addresses of hosts connected to VTEPs. Switch-1 receives a frame with destination MAC address, 00:50:56:15:16:28, which belongs to VM-2 on Switch-3. Switch-1 learns from EVPN that VM-2 is reachable through VTEP 192.168.1.2, which is Switch-3’s loopback interface. Switch-1 encapsulates the frame with VXLAN and an IP header destined to 192.168.1.2 and sends it over the underlay network1.
