H12-921_V1.0 Huawei HCIE-Data Center Network (Written) V1.0 Free Practice Exam Questions (2025 Updated)

Resolution: Option A is correct, Resolution: AZ and DC can be flexibly mapped according to the actual deployment situation. For example, in a large-scale public cloud, an AZ can contain multiple DCs, in a small and medium-sized private cloud, multiple sets of independent AZs can be set up in a DC, and a DC can be planned as one AZ, where DC and AZ are equivalent. Option B is wrong, as can be seen in the following diagram

The ratio of Router to vFW is N:1

Parse:

Resolution: IMaster NCE-FabricInsight creates a network snapshot task before configuration changes. You can create snapshots by fabric, including resource snapshots, protocol snapshots, configuration file & table entry snapshots, and telemetry metric snapshots.

Analysis: The service simulation function in iMaster NCE-Fabric provides functions such as pre-verification, simulation, and resource consumption budget for service delivery, helping you determine whether the current service orchestration can achieve the expected results, whether it will affect other existing services, and how much equipment resources are expected to consume. ▫iMaster NCE-Fabric enables the design mode for a tenant

Administrators can orchestrate VPC services and cross-VPC intercommunication services to which tenants belong. The changes made in the design state will not be directly delivered to the device, but will be superimposed on the existing configuration and the new configuration through the simulation engine for simulation modeling and analysis. In the simulation, you can directly view the devices to which the services to be deployed will be delivered, and iMaster NCE-Fabric can directly display the resource usage (consumed/consumed/total resources) on each device to avoid service delivery failures or other faults caused by insufficient network device resources. ▫ At the same time, you can preview which specific configuration commands will be delivered to the device before the network configuration is delivered to the device. ▫ During the simulation, you can check the service connectivity to see if the service connectivity meets expectations. ▫ In the simulation, you can perform a network-wide impact analysis of the tenant network to preview whether the reachability of IP flows has changed before and after the configuration change, so as to further confirm whether the configuration is correct. • Design state and production state description: Design state: ▫ The process of VPC service orchestration and simulation verification in the "Business Simulation APP" is called design state. Business orchestration in the design state.

It is delivered to the design state database and not to the real device. After the user clicks Submit, the data will be submitted to the production state and delivered to the device. ▫ Production state: The process of orchestrating VPC services and delivering devices in the Service Provisioning App is called production mode. Business orchestration in the production mode is delivered to the real physical device.

Analysis: Option A: Error, Restrict communication can also be implemented in the group Option B: Error, the source EPG group number is written to the vxlan header, and the non-destination EPG group number is written.

Analysis: IMaster NCE-Fabric carries some O&M capabilities in the overall CloudFabric solution, including network management, path detection, network reachability verification, and fault 1-3-5 closed-loop . Built on Huawei's big data platform, iMaster NCE-FabricInsight receives data reported from a variety of network devices and uses intelligent algorithms to analyze network data to quickly discover network faults and hidden O&M hazards, quickly locate network faults, present key network events, and provide decision-making basis for network O&M.

Resolution: Cinder is used for volume management.
