SPLK-1002 Splunk Core Certified Power User Exam Free Practice Exam Questions (2025 Updated)

The correct answer is B. Transforming.

The explanation is as follows:

The timechart command is a Splunk command that creates a time series chart with corresponding table of statistics12.

A timechart is a statistical aggregation applied to a field to produce a chart, with time used as the X-axis1. You can specify a split-by field, where each distinct value of the split-by field becomes a series in the chart1.

Transforming commands are commands that change the format of the search results into a data structure that can be easily visualized3. Transforming commands often use stats functions to aggregate and summarize data3.

Therefore, the timechart command is an example of a transforming command, as it transforms the search results into a chart and a table using stats functions123.

When using a field value variable with a Workflow Action, the exclamation mark (!) will escape the data. A Workflow Action is a custom action that performs a task when you click on a field value in your search results. A Workflow Action can be configured with various options, such as label name, base URL, URI parameters, post arguments, app context, etc. A field value variable is a placeholder for the field value that will be used to replace the variable in the URL or post argument of the Workflow Action. A field value variable is written as fieldn​ame, where field_name is the name of the field whose value will be used. However, if the field value contains special characters that need to be escaped, such as spaces, commas, etc., you can use the exclamation mark (!) before and after the field value variable to escape the data. For example, if you have a field value variable host, you can write it as !$host! to escape any special characters in the host field value.

Therefore, option B is the correct answer.

The Common Information Model (CIM) add-on in Splunk applies preconfigured data models to data at search time. This means that when a search is executed, the CIM add-on uses its predefined data models to normalize and map the relevant data to a common format. This approach ensures that data is interpreted and analyzed consistently across various datasets without modifying the data at index time.

The search string below returns events from the data model named Application_State.

| datamodel Application_State All_Application_State search

The search string does the following:

It uses the datamodel command to access a data model in Splunk. The datamodel command takes two arguments: the name of the data model and the name of the dataset within the data model.

It specifies the name of the data model as Application_State. This is a predefined data model in Splunk that contains information about web applications.

It specifies the name of the dataset as All_Application_State. This is a root dataset in the data model that contains all events from all child datasets.

It uses the search command to filter and transform the events from the dataset. The search command can use any search criteria or command to modify the results.

Therefore, the search string returns events from the data model named Application_State.

The maxspan function of the transaction command allows you to set the maximum total time between the earliest and latest events returned. The maxspan function is an argument that can be used with the transaction command to specify the start and end constraints for the transactions. The maxspan function takes a time modifier as its value, such as 30s, 5m, 1h, etc. The maxspan function sets the maximum time span between the first and last events in a transaction. If the time span between the first and last events exceeds the maxspan value, the transaction will be split into multiple transactions.

The delimiter method in the Field Extractor should be used when fields in events are separated consistently by a specific character (such as a comma, tab, or pipe). This method simplifies extraction without requiring complex regular expressions.

Field aliases are used to normalize different field names that contain the same type of data (like IP addresses) across multiple sourcetypes or sources, making the data CIM compliant without re-extracting the fields.

The correct answer is A. chart, timechart, stats, eventstats.

Transforming commands are commands that change the format of the search results into a table or a chart. They can be used to perform statistical calculations, create visualizations, or manipulate data in various ways1.

Transactions are groups of events that share some common values and are related in some way. Transactions can be defined by using the transaction command or by creating a transaction type in the transactiontypes.conf file2.

Some transforming commands can be used with transactions to create tables or charts based on the transaction fields. These commands include:

chart: This command creates a table or a chart that shows the relationship between two or more fields. It can be used to aggregate values, count occurrences, or calculate statistics3.

timechart: This command creates a table or a chart that shows how a field changes over time. It can be used to plot trends, patterns, or outliers4.

stats: This command calculates summary statistics on the fields in the search results, such as count, sum, average, etc. It can be used to group and aggregate data by one or more fields5.

eventstats: This command calculates summary statistics on the fields in the search results, similar to stats, but it also adds the results to each event as new fields. It can be used to compare events with the overall statistics.

These commands can be applied to transactions by using the transaction fields as arguments. For example, if you have a transaction type named “login” that groups events based on the user field and has fields such as duration and eventcount, you can use the following commands with transactions:

| chart count by user : This command creates a table or a chart that shows how many transactions each user has.

| timechart span=1h avg(duration) by user : This command creates a table or a chart that shows the average duration of transactions for each user per hour.

| stats sum(eventcount) as total_events by user : This command creates a table that shows the total number of events for each user across all transactions.

| eventstats avg(duration) as avg_duration : This command adds a new field named avg_duration to each transaction that shows the average duration of all transactions.

The other options are not valid because they include commands that are not transforming commands or cannot be used with transactions. These commands are:

diff: This command compares two search results and shows the differences between them. It is not a transforming command and it does not work with transactions.

datamodel: This command retrieves data from a data model, which is a way to organize and categorize data in Splunk. It is not a transforming command and it does not work with transactions.

pivot: This command creates a pivot report, which is a way to analyze data from a data model using a graphical interface. It is not a transforming command and it does not work with transactions.

The Field Extractor (FX) is a tool that helps you extract fields from your events using a graphical interface2. You can create a report using a custom field extracted by the FX and share it with other users in your organization2. However, if another user runs the shared report and no results are returned, there could be two possible reasons. One reason is that the extraction is private, which means that only you can see and use the extracted field2. To make the extraction available to other users, you need to make it global or app-level2. Therefore, option C is correct. Another reason is that the other user does not have access to the index where the events are stored2. To fix this issue, you need to grant the appropriate permissions to the other user for the index2. Therefore, option D is correct. Options A and B are incorrect because they are not related to the field extraction or the report.

The fillnull command replaces null or missing values in specified fields with a given replacement value. In this example, the command sets the src field to "Unknown" wherever it is null. It does not affect other fields or convert values from "Unknown" back to null.

The Field Extractor (FX) is a tool that helps you extract fields from your events using a graphical interface or by manually editing the regular expression2. The FX allows you to create field extractions that persist as knowledge objects, which are entities that you create to add knowledge to your data and make it easier to search and analyze2. Field extractions are methods that extract fields from your raw data using various techniques such as regular expressions, delimiters or key-value pairs2. When you create a field extraction using the FX, you can save it as a knowledge object that applies to your data at search time2. You can also manage and share your field extractions with other users in your organization2. Therefore, option C is correct, while options A, B and D are incorrect because they do not describe the use of the FX.

The descriptions of the data models that come with the Splunk Common Information Model (CIM) Add-on are documented in the CIM Add-on manual (Option B). This manual provides detailed information about the data models, including their structure, the types of data they are designed to normalize, and how they can be used to facilitate cross-sourcing reporting and analysis.

Selected fields are fields that you choose to display in your search results by clicking on them in the Fields sidebar or by using the fields command2. Selected fields are displayed below each event in the search results, along with their values2. Therefore, option A is correct, while options B, C and D are incorrect because they are not places where selected fields are displayed.

Search workflow actions are custom actions that run a search when you click on a field value in your search results. Search workflow actions can be configured with various options, such as label name, search string, time range, app context, etc. One of the options is to define the time range of the search when creating the workflow action. You can choose from predefined time ranges, such as Last 24 hours, Last 7 days, etc., or specify a custom time range using relative or absolute time modifiers. Search workflow actions do not run as real-time searches by default, but rather use the same time range as the original search unless specified otherwise. Search workflow actions cannot be configured as scheduled searches, as they are only triggered by user interaction. Search workflow actions can be configured with any valid search string that includes any search command, such as transaction.
