301a F5 BIG-IP LTM Specialist: Architect, Setup, and Deploy (301a) Free Practice Exam Questions (2026 Updated)

Prepare effectively for your F5 301a BIG-IP LTM Specialist: Architect, Setup, and Deploy (301a) certification with our extensive collection of free, high-quality practice questions. Each question is designed to mirror the actual exam format and objectives, complete with comprehensive answers and detailed explanations. Our materials are regularly updated for 2026, ensuring you have the most current resources to build confidence and succeed on your first attempt.

Page: 1 / 3
Total 189 questions

An LTM Specialist needs to upgrade all guests on a Viprion eight CMP guests.

What is the maximum number of guests that the LTM Specialist should upgrade at once?

A.

Eight

B.

One

C.

TWO

D.

Four

Explanation

Each guest is independent, just like hardware upgrades. Can only upgrade one by one, there is no way to upgrade at the same time.

An LTM device configured with a management IP address and route and a series of self-IPs and TMM routes. Both management and TMM have a routing entry for 101 10/24 Application traffic is being load balanced and sent to pool member 10.1.1.123 with SNAT Automap and configured.

Which route will the LTM device use?

A.

TMM route regardless of the management port status

B.

both routes, which will duplicate traffic on both management and TMM interface

C.

equal cost multipath load balancing via both routes

D.

management route when TMM interface is down or TMM is offline

E.

management route regardless of the management port status

An LTM Specialist regularly provides analytics reports that show that traffic generated by different subnets within the organization. The LTM Specialist needs show the associate department names next the IP addresses in the reports.

Which step should the LTM Specialist take to meet this requirement?

A.

use an iRule to change the output of the report

B.

export the report and add the department names manually

C.

create VLANs for each subnet and set the name accordingly

D.

define active subnets and assign a name to certain subnets

AN LTM Specialist is deploying an iRule designed to determine the country of origin of an incoming client connection. The iRule needs to be used with an SSL-enabled web application.

Which profile required for the iRule to function properly?

A.

HTTP

B.

DNS

C.

TCP

D.

UDP

Question stem requires the client IP to match the source region, so TCP ?UDP at the transport layer can meet the requirements. The title stem mentions that it is a Web application based on SSL, and it does not mention F5 undertakes SSL offload, So TCP is enough.

Forward original client IP through HTTP

An existing service has been deployed on a BIG-IP LTM device and is functioning as expected. A new request requires the client IP address to be forwarded to the backend service. Which profile is required for this functionality? (Choose one answer.)

A.

OneConnect Profile

B.

Source Address Translation

C.

SSL Profile (Server)

D.

HTTP Profile

A BIG-IP system load balances connections to a web application. A TCP-based Denial of Service attack against the web application is occurring, which has caused very high memory utilization on the LTM device due to stale TCP connections.

Which TCP profile option should be used to reduce memory utilization?

A.

Idle timeout

B.

Reset on timeout

C.

Slow Start

D.

Multipath TCP

Node with ICMP and TCP monitors

A node is assigned two monitors. A packet capture shows ICMP echo requests and replies with 10.128.20.12, an HTTP TCP connection receiving a reset, and an HTTPS TCP connection that successfully establishes to 10.128.20.12:443. What is the status of a pool member running on that node and listening on port 443? (Choose one answer.)

A.

Unavailable

B.

Up

C.

Unknown

D.

Down

TCP monitors: service and shared dependency

An LTM Specialist needs to assign health monitors to a pool with two members, 10.10.10.101 and 10.10.10.102, both listening on TCP port 8080. Application health also depends on another server at 10.10.10.100 listening on TCP port 9080. Which two custom TCP monitors should be selected? (Choose two answers.)

A.

A custom TCP monitor on port 9080 with 10.10.10.100 as alias address

B.

A custom TCP monitor on port 9080

C.

A custom TCP monitor on port 8080

D.

A custom TCP monitor on port 8080 with 10.10.10.101 as alias address

E.

A custom TCP monitor on port 8080 with 10.10.10.102 as alias address

F.

A custom TCP monitor on port 9080 with 10.10.10.101 as alias address

Intermediate certificate in Client SSL chain

A new SSL certificate is being installed for an existing web application. The certificate is signed by an intermediate CA, and that CA has provided the intermediate certificate. Which action should be taken? (Choose one answer.)

A.

Import the intermediate certificate and add it to the Trusted Certificate Authorities

B.

Import the intermediate certificate and add it to the Server SSL profile

C.

Import the intermediate certificate and add it to the Client SSL profile certificate chain

D.

Import the root CA certificate on the users’ desktops

vCMP eight-guest upgrade limit

An LTM Specialist needs to upgrade all guests on a VIPRION running eight vCMP guests. What is the maximum number of guests that the LTM Specialist should upgrade at once? (Choose one answer.)

A.

Eight

B.

Two

C.

One

D.

Four

A new HTTP server has been deployed on an LTM device. The application running on the server must be monitored by the LTM device. The following is required:

A new HTTP server has been deployed on an LTM device. The application running on the server must be monitored by the LTM device. The following is required:

When the server is unavailable, it will send an HTTP status code of 200 in response to a request for the status html page.

When the server is available. I will send and HTTP status code of 201 in response to a request for the status html page.

When the 200 status code is received, the pool member should receive No new connections.

Which configuration change should be made to meet these requirements?

A.

set the Send String to GET/ status html and the Receive String to 200 and Receive Disable String to 201.

B.

set the Send String to GET Arian and the Receive String to 200 and Receive Disable String to 201.

C.

set the Send String to GET Arian and the Receive Disable String to 200 and Receive String to 201.

D.

set the Send String to Get /status html and the Receive Disable String to 200 and Receive String to 201.

A customer wants to select the pool for an application based on information found in the path of the URL.

For example:

http://www.example.com/app 1 should be sent to the app 1 pool

http.//www.exampie.com/app 2 should be sent to the app2 pool

Which two profiles need to be assigned to the virtual server? (Choose two.)

A.

Client SSL

B.

Persistence

C.

TTP Compression

D.

HTTP

E.

TCP

A Client makes the request displayed below to the application server.

Which virtual server type should an LTM Specialist use to load balance based on the URI?

A.

Forwarding (Layer 2)

B.

Stateless

C.

Standard

D.

Performance (Layer 4)

The picture belongs to static content, you can configure static content cache in FS to meet this demand

An LTM Specialist must configure session persistence for a highly available, highly utilized web-based application.

* The following requirements are provided:

* http proxy setup for security

persistence information available to the HA peer in case of failover

The LTM Specialist needs to minimize additional burden on the LTM device to the greatest extent possible.

Which persistence profile should be used?

A.

Cookie insert

B.

Universal

C.

Source Address Affinity

D.

Destination Address Affinity

In an iApp, which configuration protects against accidental changes to an application Services configuration?

A.

Components

B.

Strict Updates

C.

Name

D.

Template

Standard virtual server across two ISPs

Which Standard Virtual Server settings should an LTM Specialist use to load balance across routed paths of two different ISPs? (Choose one answer.)

A.

Address translation disabled and port translation enabled

B.

Address translation enabled and port translation disabled

C.

Both address and port translation enabled

D.

Both address and port translation disabled

Exhibit.

The LTM devices LTM1 and LTM2 are configured in a Device Group (Sync Failover) with Network Failover configured on both the management and HA and Internal VLANS. and ConfigSync is confined in a Device Group (Sync Failover) with Network Failover and internal are tagged on a single trunk with subnets Connection Mirroring is configured on both the HA interlace directly connected between LTM1 and LTM2, and the management interlace is connected to a management switch. The LTM devices have four Traffic Groups defined, and both LTM devices are healthy and capable of passing traffic for any of the Traffic Groups.

An LTM Specialist disconnects the cable for the HA network in an effort to test failover.

Which HA functionality works in this case?

A.

ConfigSync does NOT work. Connection Mirroring floes NOT work.

B.

ConfigSync works Connection Mirroring works

C.

ConfigSync works. Connection Mirroring docs NOT work

D.

ConfigSync does NOT work; Connection Mirroring works

AVR email SMTP profile

In which Application Visibility and Reporting (AVR) profile must the SMTP profile be defined to configure notifications via email? (Choose one answer.)

A.

Custom analytics profile

B.

Virtual server profile

C.

Default analytics profile

D.

iApp analytics profile

Refer to the exhibit.

An LTM Specialist configures the two syslog destination Syslog destination #1 can receive messages but the syslog destination #2 can NOT receive messages.

Which command sill correct the issue?

A.

{/Common)(tmos) # modify /syssyslog remote-servers modify (syslog_dest2 {local-ip

B.

{/Common)(tmos) # modify Ays syslog remote servers modify {syslog_dest2 {local- ip 10.208.102 254)}

C.

{/Common) (tmos) # modify /sys syslog remote-servers modify {syslog_dest2 {host 10 208.102.254 }}

D.

{Common(tmos) # modify/syslog remote-servers modify {syslog_dest2 {lost.10.10.10.28 }}

An LI M device is experiencing a high volume of traffic. The virtual server is struggling under the load. The problem appears to be on the server side connections. The virtual server is accepting connections . The virtual server is accepting connections on https and is configured with an SSL profile and http pool.

What should be added to increase the performance of the device?

A.

an HTTP Compression profile

B.

a One Connect profile

C.

smaller key to the SSL profile

D.

a SPDY profile

Page: 1 / 3
Total 189 questions
