FCP_FAZ_AN-7.6 Fortinet NSE 5 - FortiAnalyzer 7.6 Analyst Free Practice Exam Questions (2026 Updated)

When a generated report does not include the expected information despite the logs being present, there are several factors to check to ensure accurate datarepresentation in the report.

Option A - Check the Time Frame Covered by the Report:

Reports are generated based on a specified time frame. If the time frame does not encompass the period when the relevant logs were collected, those logs will not appear in the report. Ensuring the time frame is correctly set to cover the intended logs is crucial for accurate report content.

Conclusion:Correct.

Option B - Disable Auto-Cache:

Auto-cache is a feature in FortiAnalyzer that helps optimize report generation by using cached data for frequently used datasets. Disabling auto-cache is generally not necessary unless there is an issue with outdated data being used. In most cases, it does not directly impact whether certain logs are included in a report.

Conclusion:Incorrect.

Option C - Increase the Report Utilization Quota:

The report utilization quota controls the resource limits for generating reports. While insufficient quota might prevent a report from generating or completing, it does not typically cause specific log entries to be missing. Therefore, this option is not directly relevant to missing data within the report.

Conclusion:Incorrect.

Option D - Test the Dataset:

Datasets in FortiAnalyzer define which logs and fields are pulled into the report. If a dataset is misconfigured, it could exclude certain logs. Testing the dataset helps verify that the correct data is being pulled and that all required logs are included in the report parameters.

Conclusion:Correct.

Conclusion:

Correct Answer:A. Check the time frame covered by the reportandD. Test the dataset.

These actions directly address the issues that could cause missing information in a report when logs are available but not displayed.

When a generated report does not contain the expected information even though the logs are confirmed to be present, it typically indicates anissue with the report's configuration. There are a few common reasons this might happen:

Option A - Check the Time Frame Covered by the Report:

Reports are generated based on a specific time frame. If the report’s time frame does not cover the period when the relevant logs were collected, those logs won’t appear in the report output. Verifying and adjusting the time frame is essential to ensure the report includes all relevant data.

Conclusion:Correct.

Option B - Disable Auto-Cache:

Auto-cache is designed to improve report generation speed by using cached data. Disabling auto-cache would typically only be relevant if the report is pulling outdated data from cache, but it doesn’t directly affect whether specific logs are included in a report.

Conclusion:Incorrect.

Option C - Increase the Report Utilization Quota:

The report utilization quota is related to the resource limits for generating reports. It does not directly influence whether certain data appears in a report. Increasing this quota would help only if there are resource issues preventing the report from completing, not if specific logs are missing from the report.

Conclusion:Incorrect.

Option D - Test the Dataset:

Datasets determine which logs and data fields are pulled into the report. If a dataset is configured incorrectly or does not include the required log fields, it could lead to missing information. Testing the dataset allows you to verify that it’s correctly configured and pulling the expected data.

Conclusion:Correct.

Conclusion:

Correct Answer:A. Check the time frame covered by the reportandD. Test the dataset.

These steps directly address the issues that could lead to missing information in a report when logs are available but not displayed.

The command diagnose sql statussqlreportd is used in FortiAnalyzer to obtain specific information about the SQL reporting process and caching status. Here’s what this command accomplishes and an analysis of each option:

Command Functionality:

sqlreportd is the FortiAnalyzer daemon responsible for managing SQL-based reporting processes.

The diagnose sql status sqlreportd command provides information on active SQL query connections and thehcache(historical cache) status, which helps in monitoring and troubleshooting SQL report generation.

Option Analysis:

Option A - To View a List of Scheduled Reports:

This option is incorrect because the command does not list scheduled reports. Instead, it focuses on SQL reporting processes and cache details.

Option B - To List the Current SQL Processes Running:

While the command may show active SQL connections, its primary focus is not a detailed list of all SQL processes but rather the connections and cache status for reporting.

Option C - To Display the SQL Query Connections and hcache Status:

This is correct. The command specifically provides information on SQL query connections related to the reporting process (sqlreportd) and displays thehcachestatus.

Option D - To Identify the Database Log Insertion Status:

This is incorrect. The command does not provide details on log insertion status. Log insertion status is typically monitored through different diagnostic commands focused on database processes and log handling.

Conclusion:

Correct Answer:C. To display the SQL query connections and hcache status

This command is used to monitor SQL reporting activities and cache status, aiding in the analysis of report generation performance and connection health.

Comprehensive and Detailed Explanation From Exact Extract of knowledge of FortiAnalyzer 7.6 Study guide documents:

The FortiAnalyzer study guide explains that IOC identification is performed by comparing relevant log fields against the FortiGuard threat database. Specifically, it states:“Depending on the log type, FortiAnalyzer identifies possible compromised hosts by checking the threat database against the log's IP address, domain, and URL.”

From this extract, two of the explicit parameters FortiAnalyzer uses for IOC detection areIP addressandURL(both listed verbatim). Policy ID and application category are not part of the IOC matching parameters described for threat-database checks in this context.

This is further consistent with the study guide’s definition of indicator types, which states:“There are three types of indicators: IP addresses, URLs, and domains.”

In FortiAnalyzer’s SQL query syntax, the typical order for querying the database follows the standard SQL format, which is:

SELECT FROM <title> WHERE GROUP BY

Option Dcorrectly follows this structure:

SELECT devid FROM $log: This specifies that the query is selecting the devid column from the $log table.

WHERE 'user' = ': This part of the query is intended to filter results based on a condition involving the user column. Although there appears to be a minor typographical issue (possibly missing the user value after =), it structurally adheres to the correct SQL order.

GROUP BY devid: This groups the results by devid, which is correctly positioned at the end of the query.

Let’s briefly examine why the other options are incorrect:

Option A: SELECT devid FROM $log GROUP BY devid WHERE 'user', 'users1'

This is incorrect because the GROUP BY clause appears before the WHERE clause, which is out of order in SQL syntax.

Option B: SELECT FROM $log WHERE devid 'user', USER1' GROUP BY devid

This is incorrect because it lacks a column in the SELECT statement and the WHERE clause syntax is malformed.

Option C: SELCT devid WHERE 'user' - 'USER1' FROM $log GROUP BY devid

This is incorrect because the SELECT keyword is misspelled as SELCT, and the WHERE condition syntax is invalid.

Comprehensive and Detailed Explanation From Exact Extract of knowledge of FortiAnalyzer 7.6 Study guide documents:

FortiAnalyzer supports moving reporting content across ADOMs by importing/exporting reporting objects, but it enforces ADOM compatibility. The study guide states: “You can, however,import and export reports and charts… into different ADOMs …” and explicitly requires that “Both ADOMs must be of the same type.” This directly validates statementA.

For report dependencies, the study guide clarifies how datasets are handled during transfer. While “You can’t export templates and datasets,” it also explains that when you export a chart, “the associated dataset is exported with it, so when you import an exported chart,the associated dataset is imported as well.” Since reports are composed of charts (and charts depend on datasets), moving a report between ADOMs entails moving its charts; when those charts are exported/imported, their datasets come with them. This supports statementCbased on the documented chart→dataset import/export behavior.

StatementDis not required because the study guide explicitly indicates you can “export and import reports” directly, and additionally notes that on import “you can save the layout of the report as a template” (optional, not a prerequisite).

When a new playbook is created on FortiAnalyzer, the system requires some time toparse and validatethe playbook before it can be executed. Parsing involves checking the playbook's structure, ensuring that all syntax and logic are correct, and preparing the playbook for execution within FortiAnalyzer’s automation engine. This initial parsing step is necessary for FortiAnalyzer to load the playbook into its operational environment correctly.

Here’s why the other options are incorrect:

Option A: FortiAnalyzer needs that time to parse the new playbook

This is correct. The delay is due to the parsing and setup process required to prepare the new playbook for execution. FortiAnalyzer’s automation engine checks for any issues or dependencies within the playbook, ensuring that it can run without errors.

Option B: FortiAnalyzer needs that time to debug the new playbook

This is incorrect.Debugging is not an automatic process that FortiAnalyzer undertakes after playbook creation. Debugging, if necessary, is a manual task performed by the administrator if there are issues with the playbook execution.

Option C: FortiAnalyzer needs that time to back up the current playbooks

This is incorrect. FortiAnalyzer does not automatically back up playbooks every time a new one is created. Backups of configuration and playbooks are typically scheduled as part of routine maintenance and are not triggered by playbook creation.

Option D: FortiAnalyzer needs that time to ensure there are no other playbooks running

This is incorrect. FortiAnalyzer can manage multiple playbooks running simultaneously, so it does not require waiting for other playbooks to finish before initiating a new one. The waiting time specifically relates to the parsing process of the newly created playbook.

To ensure that reports generated by FortiAnalyzer are automatically sent to an email inbox, you need to set up an output profile for the reports. Output profiles specify where and how reports should be delivered, including the option to send them via email.

Option A - Enable the Option to Email All Reports Under the Mail Server:

The mail server configuration allows FortiAnalyzer to send emails but does not automatically enable email distribution for reports. This setting alone does not specify which reports to send or to whom.

Conclusion:Incorrect.

Option B - Add a mailto:<</b>email address> Option Within the Report Layouts:

Adding an email address within the report layout is not a standard configuration option for report distribution. Report layouts define the format andcontent of the report but not its distribution method.

Conclusion:Incorrect.

Option C - Enable Email Notification Under the Report Calendar:

The report calendar is used to schedule when reports are generated. While it triggers report generation at specific times, it does not handle email distribution. Emailing reports requires a configured output profile.

Conclusion:Incorrect.

Option D - Enable an Output Profile on the Reports:

An output profile can be configured on FortiAnalyzer to define delivery options, including emailing the report to specified recipients. This setup ensures that every time a report is generated according to the schedule, it is automatically emailed to the configured address.

Conclusion:Correct.

Conclusion:

Correct Answer:D. Enable an output profile on the reports.

Configuring an output profile is the correct way to set up automatic email distribution of generated reports in FortiAnalyzer.
