H12-811_V1.0 Huawei HCIA-Datacom V1.0 Exam Free Practice Exam Questions (2025 Updated)

Comprehensive Explanation: In RSTP (Rapid Spanning Tree Protocol), G0/0/3 of SWB is an Alternate Port because it provides a redundant path to the root bridge, while G0/0/3 of SWA is a Designated Port, forwarding traffic away from the root bridge. Similarly, G0/0/2 of SWA is also a Designated Port because it forwards traffic to other segments of the network. Alternate Ports are used to provide backup paths, while Designated Ports are the forwarding ports on a given segment.

Python is known for clear syntax and ease of learning, but it is not highly efficient at runtime due to being an interpreted language.

Option A (Correct): Python has a vast ecosystem of third-party libraries.

Option B (Incorrect - Answer): Python is easy to learn but is not as fast as compiled languages like C or Java.

Option C (Correct): Python is widely used in O&M, AI, and data science.

Option D (Correct): Python is fully open-source.

Thus, the correct answer is B.

Detailed Explanation:

Dynamic routing protocols, such as OSPF and RIP, automatically discover and generate routes, adjusting when network topology changes occur. This helps in reducing the manual configuration required by static routes and ensures that the network adapts efficiently to changes such as link failures or the addition of new routes.

How Routers Handle Packets:

Routers do not change the destination IP address when forwarding packets.

The destination IP remains the same to ensure the packet reaches the intended recipient.

Router’s Role:

Routers inspect the destination IP, determine the best path using routing tables, and forward the packet accordingly.

Conclusion:

The destination IP address remains unchanged; hence, the statement is FALSE.

References: HCIA-Datacom V1.0 Certification Guide, Chapter 2: IP Forwarding.

Detailed Explanation:The priority (preference) of static routes can indeed be manually specified in Huawei devices. By default, static routes have a preference of 60, but this can be changed to create backup routes or prioritize certain routes over others.

In DHCP (Dynamic Host Configuration Protocol):

The client starts renewal at 50% (0.5) of the lease time to extend its lease with the DHCP server.

If unsuccessful, it tries again at 87.5% (0.875) before the lease expires.

Option A (Incorrect - 0.875): This is the second attempt if the first renewal fails.

Option B (Correct - 0.5): The first renewal attempt occurs when the lease reaches 50% of its duration.

Option C (Incorrect - 0.25): No renewal attempt happens at 25%.

Option D (Incorrect - 1): At 100% lease expiration, the IP is released and a new request is needed.

Thus, the correct answer is B.

TPID Definition:

TPID (Tag Protocol Identifier) is a field in the Ethernet frame header that indicates the presence of an 802.1Q VLAN tag.

IEEE 802.1Q defines the TPID value as 0x8100.

Why Other Options Are Incorrect:

0x9100: Used in some proprietary protocols but not IEEE standard.

0x8200 and 0x7200: Not valid TPID values.

References: HCIA-Datacom V1.0 Certification Guide, Chapter 4: VLAN Basics.

Comprehensive and Detailed Explanation:

Spanning Tree Protocol (STP) prevents switching loops in networks with redundant links by:

Blocking certain links while still maintaining redundancy.

Preventing broadcast storms and MAC table instability.

Reactivating backup links if the primary link fails.

✅ Reference: HCIA-Datacom Switching Guide – STP Loop Prevention

Detailed Explanation:If the username does not contain the delimiter "@" followed by a domain name, the user is automatically assigned to the default domain. In this case, since the username "huawei" does not specify a domain, the user belongs to the default domain​​.

Detailed Explanation:The address 145.4.2.55/26 is a valid unicast address and falls within the range of usable IP addresses for a /26 subnet. The address 237.6.1.2/24 is from a reserved range, 127.3.1.4/28 is part of the loopback range (127.0.0.0/8), and 192.168.10.112/30 only provides two usable addresses, which would not allow the router to be properly configured .

Detailed Explanation:In this scenario, the MAC address 00e0-fc99-9999 is associated with multiple IP addresses through dynamic ARP learning, indicating that the host’s IP has changed several times. The ARP table on the switch shows multiple entries with different IPs mapped to the same MAC address, which is common when a device frequently updates its IP. As ARP is a dynamic protocol, these entries reflect the device's current and past IP associations. (Reference: HCIA-Datacom Training Material, ARP Operation and IP-MAC Mapping)

Eth-Trunk Functionality:An Eth-Trunk interface can operate as both a Layer 2 and Layer 3 interface depending on the configuration. For example:

As a Layer 2 interface, it can aggregate Ethernet links for switching.

As a Layer 3 interface, it can aggregate links for routing​.

Correct Answer:FALSE. Eth-Trunk interfaces can function as both Layer 2 and Layer 3 interfaces.

In OSPF (Open Shortest Path First), routers exchange database information in multiple stages.

ExStart State (Correct Answer):

The Master/Slave relationship is determined in this phase.

The router with the higher Router ID becomes the Master, and the other becomes the Slave.

The Master initiates the exchange of Database Description (DD) packets.

2-way State (Incorrect): This state is reached when two routers recognize each other as neighbors but have not started database exchange.

Exchange State (Incorrect): The actual exchange of DD packets happens in this state, but the Master/Slave roles are already established in ExStart.

Full State (Incorrect): This is the final state where routers have synchronized their link-state databases.

Thus, the correct answer is D (ExStart).

SNMP Message Types:

get-request: Sent by the NMS to retrieve data from a device.

set-request: Used by the NMS to modify device settings.

get-response: Sent by the device in response to a get-request.

trap: Sent automatically by a device to notify the NMS of an event.

Why "trap" Is Correct:

If a registered event occurs (e.g., interface down, high CPU usage), the device proactively sends a trap to alert the NMS.

Conclusion:

Since traps notify abnormal events, the correct answer is A (trap).

References: HCIA-Datacom V1.0 Certification Guide, Chapter 7: SNMP and Network Monitoring.

Detailed Explanation:Static MAC address entries are manually configured and stored in the switch's configuration file, making them persistent across reboots. These entries remain in the MAC address table after a restart, unlike dynamic entries, which are lost. (Reference: HCIA-Datacom Training Material, MAC Address Table Types)

Detailed Explanation:The Type/Length field value of 0x0800 indicates that the upper-layer protocol is IPv4. However, the length of the IPv4 header can range from 20 to 60 bytes, not the length of the entire upper-layer packet. The field refers to the type of the encapsulated protocol, and the length is not constrained to the header alone​​.

Comprehensive and Detailed Explanation:

In PPP (Point-to-Point Protocol) connections, a static route can be configured using:

Next-hop IP address

Outbound interface

Since PPP links are point-to-point, the router can directly forward packets without needing an explicit next-hop address.

Example configurations:

ip route-static 10.1.1.0 24 Serial0/0/0

ip route-static 10.1.1.0 24 192.168.1.2

✅ Reference: HCIA-Datacom Routing Guide – Static Route Configuration on PPP
