CIS-Discovery ServiceNow Certified Implementation Specialist - Discovery Free Practice Exam Questions (2025 Updated)

To launch any pattern, you need to specify the CI classification and the CI type. The CI classification determines the table where the discovered CI is stored in the CMDB, and the CI type defines the specific attributes and relationships of the CI. For example, if you want to discover a Windows server, you need to select the CI classification as cmdb_ci_win_server and the CI type as Windows Server. These choices are mandatory for any pattern, as they enable Discovery to identify and classify the CIs correctly.

A horizontal discovery pattern is a set of steps that execute operations to identify, classify, and populate attributes for configuration items (CIs) of a specific category or class, such as infrastructure or application. A horizontal pattern can be applied to any operating system or platform that supports the required protocols and commands12.

Discovery finds and maps dependencies for the following types of storage devices: Direct-attached storage (DAS), network-attached storage (NAS), or storage area network (SAN)1. NAS or SAN storage that is discovered via a Storage Management Initiative Specification (SMI-S) and Common Information Model (CIM) is also supported2. Discovery collects information about storage area networks from specialized devices, such as storage arrays and Fibre Channel (FC) switches, and creates specific references between the tables in the SAN3. Discovery does not support Multiple area network (MAN) or Redundant Array of Independent Disks (RAID) as types of storage devices.

The ECC Queue is the normal connection point between an instance and other systems that integrate with ServiceNow, such as MID Servers1. The ECC Queue displays input and output messages from and to MID Servers2. The actual XML payload that is sent to or from an instance is stored in the ECC Queue3. The ECC Queue also provides a connected flow of probe and sensor activity, as probes are sent from the instance to the MID Server, and sensors are sent from the MID Server to the instance2.

The recommended method for excluding specific software from discovery on Windows and Unix Servers in ServiceNow Discovery is by modifying the probes. Probes are the components in ServiceNow that collect data from devices. By modifying the probes, specific software can be excluded from the discovery process. Options A, C, and D are less direct methods for achieving this specific requirement.References= ServiceNow Discovery documentation, particularly in the sections related to probe configuration and modification.

 Discovery can provide information about the relationships between configuration items (CIs), including applications and hosts. Application relationships are the connections between applications that run on different hosts or servers, such as web servers, databases, load balancers, etc. Host relationships are the connections between applications and the hosts or servers that they run on, such as Windows, Linux, Unix, etc. Discovery can identify these relationships using various methods, such as probes, sensors, patterns, file-based discovery, etc. Discovery can also create and update these relationships in the CMDB, using the Depends on::Used by or Runs on::Runs relationship types.

A horizontal pattern is a type of Discovery pattern that discovers configuration items (CIs) and their relationships by moving across the network from one device to another. A horizontal pattern can use the Change user operation to switch from the default credentials to any other appropriate credentials for a specific device or application. This operation allows the pattern to access different types of CIs with different authentication methods.

CI identifiers can be viewed under the CI record1. A CI identifier is a set of attributes that uniquely identify a CI of a specific class2. CI identifiers are used by the identification and reconciliation engine (IRE) to match incoming data with existing CIs in the CMDB3. CI identifiers can be viewed and edited in the CI record by clicking the Identification Information related link1.

Variables are used in discovery patterns to store and manipulate data that is collected or calculated during the discovery process. There are three kinds of variables used in discovery patterns12:

CI attributes: These are variables that correspond to the attributes of the configuration item (CI) type that the pattern is discovering. For example, name, serial_number, manufacturer, etc. CI attributes are used to populate the CI record in the CMDB with the information gathered by the pattern.

Temporary: These are variables that are created and used within the pattern, but are not stored in the CMDB. For example, $result, $output, $user_var, etc. Temporary variables are used to store and manipulate data such as the output of a command, the value of a parameter, or the result of a calculation.

Global: These are variables that are defined in the global scope and can be accessed by any pattern. For example, $mid, $target, $ip_address, etc. Global variables are used to store and access data that is common to all patterns, such as the MID Server, the target device, or the IP address.

The Discovery Dashboard provides a summary of the Discovery status, including the number of active discovery errors, the number of devices discovered, and the number of credentials used. Each error has a help link that provides more information about the cause and possible solutions.

When increasing the maximum number of threads for a MID Server in ServiceNow Discovery, it's often necessary to also increase the memory allocated to the MID Server application. This is because more threads can result in higher memory usage as each thread may consume resources while performing discovery tasks. Increasing disk space, updating ACL rules for CMDB tables, or increasing the MID Server max payload size are not directly related to the number of threads used by a MID Server.References= ServiceNow Discovery documentation, especially sections discussing MID Server configuration and performance tuning.

SNMP credentials are used by Discovery to communicate with devices that support the Simple Network Management Protocol (SNMP). SNMP credentials do not include a user name, just a password, called the community string. The default read-only community string for many SNMP devices is public, and Discovery will try that automatically. Enter the appropriate SNMP credentials if they differ from the public community string1.

 According to the ServiceNow Discovery documentation, the base system CI Identifiers for Windows Server class are name and serial_number. These are the attributes that Discovery uses to uniquely identify a Windows Server CI. If both attributes match an existing CI, Discovery updates that CI. If only one attribute matches, Discovery creates a new CI. If neither attribute matches, Discovery also creates a new CI. In this scenario, the serial_number is the same for both Windows Servers, but the name is different. Therefore, Discovery will create two separate CIs, one with WindowsSN1 as the name and one with WindowsSN2 as the name.

A Discovery schedule of type Configuration Item collects complete information from the scanned IP ranges and sends it to the CMDB. This type of schedule runs a series of probes and sensors to identify and classify the devices and applications on the network, and to create or update the corresponding configuration items in the CMDB. A Discovery schedule of type Configuration Item can also run patterns to discover more details and relationships about the configuration items.

The default thread count for a MID Server is 25. This means that the MID Server can run up to 25 worker threads simultaneously to execute the jobs assigned to it by the ServiceNow instance. The worker threads are divided into different thread pools based on the priority of the jobs. The MID Server can also adjust the thread count dynamically based on the system resources and the workload. The thread count can be configured by changing the MID Server parameters in the ServiceNow instance12. References = 1: MID Server Max Threads - Worker Groups - Priority and Queues - ServiceNow 2: Product Documentation | ServiceNow

Based on the image, the value assigned to the label “Value” is a concatenation of variables and strings. One of the variables is $name_details[1].exec_info, which indicates that $name_details is a tabular variable, meaning an array or a map that can store multiple values1. The [1] is the index or the key that accesses the element of the tabular variable. The .exec_info is the attribute or the property of the element. Therefore, the choice D is true.

The other choices are not true based on the image. The choice A is false because the image does not show any WMI query operation step. A WMI query operation step is a pattern step that executes a WMI query on a Windows device and returns the results as a tabular variable2. The image does not show any WMI query syntax or result. The choice B is false because there is no scalar variable labeled ‘1’. A scalar variable is a variable that can store only one value1. The image shows a label “Value” but not a variable name. The choice C is false because the value can be used in a pattern step. A pattern step is a unit of logic that performs a specific action during Discovery or Service Mapping3. The value can be used as an input or an output of a pattern step, depending on the context.

 Reconciliation rules are used to determine which data sources can update CI attributes in ServiceNow. Reconciliation rules can be static or dynamic, and they can be applied to specific CI classes, attributes, or discovery sources. Reconciliation rules can also specify the actions to take when there are unmatched values, such as removing, ignoring, or updating them1.

 A scheduled job is a background process that runs at a specified time or interval to perform a specific task1. It is not a method for deleting specific CIs that are not discovered in 30 days. The other options are methods for deleting or updating CIs based on discovery data. A UI policy is a script that can dynamically change the behavior of a form or list2. A service mapping is a process that creates a map of the relationships between CIs that support a business service3. A data policy is a rule that enforces data consistency and accuracy by validating the data entered into a record.
