OGA-031 The Open Group ArchiMate 3 Part 1 Examination Free Practice Exam Questions (2025 Updated)

Based on the ArchiMate 3 documents or objectives, a technology function represents a collection of technology behavior that can be performed by a node. The diagram uses a composition relationship to indicate that technology function A consists of four other technology functions. The notation for a composition relationship is a solid line with a filled diamond at the end that points to the whole element. The diagram also uses an information flow relationship to indicate that information is exchanged from Administrate Replication to the other functions. The notation for an information flow relationship is a dashed line with an open arrowhead at the end that points to the direction of the flow.

References: ArchiMate® 3.2 Specification, Chapter 4 Generic Metamodel, Section 4.1 Behavior and Structure Elements, Subsection 4.1.2 Structural Relationships 1; ArchiMate® 3.2 Specification, Chapter 11 Technology Layer, Section 11.2 BehaviorElements 1; ArchiMate® 3.2 Specification, Chapter 5 Relationships, Section 5.5 Other Relationships 1; ArchiMate Patterns – Technology Layer – General Geekery 2.

Based on the ArchiMate 3 documents or objectives, a data object is a passive structure element that represents a piece of data that can be manipulated by behavior elements such as application functions or services. A passive structure element is a structural element that cannot perform behavior. Active structure elements can perform behavior on passive structure elements.

References: ArchiMate® 3.2 Specification, Chapter 4 Generic Metamodel, Section 4.1 Behavior and Structure Elements, Subsection 4.1.1 Active Structure Elements 1; ArchiMate® 3.2 Specification, Chapter 10 Application Layer, Section 10.2 Passive Structure Elements 1.
