300-425 Cisco Designing Cisco Enterprise Wireless Networks (ENWLSD) Free Practice Exam Questions (2025 Updated)

The mesh backhaul link uses Advanced Encryption Standard (AES) for encryption. AES is a robust encryption standard that is widely used in various security protocols, including WPA2 and WPA3, to provide a high level of security for wireless communications. It ensures that the data transmitted over the mesh backhaul link is protected against unauthorized access and eavesdropping.

References: CCNP Enterprise Wireless Design ENWLSD 300-425 and Implementation ENWLSI 300-430 Official Cert Guide Premium Edition and Practice.

 VLAN Select is a feature that allows for the assignment of clients to different VLANs based on various criteria, such as user credentials or device type. In a centralized wireless deployment with N+1 high availability, incorporating VLAN Select can ensure that clients maintain consistent IP addressing across failovers, preventing them from being assigned IP addresses from a different subnet.

For pervasive coverage in an oil terminal that supports casual web and email traffic over 5 GHz, disabling lower data rates can help improve overall network efficiency. Lower data rates can cause the network to slow down because they take up more airtime. By disabling rates below 24 Mbps, the APs can focus on providing higher throughput for users. Keeping the power assignment as auto allows the APs to adjust their power levels dynamically for optimal coverage and client performance

Typically, a Cisco workgroup bridge can support up to 20 wired client connections. This allows for a reasonable number of devices to be connected while maintaining performance.

For high availability pairing of two Cisco WLCs for client SSO, it is essential that both controllers have the same number of licenses to ensure feature parity and seamless failover. Additionally, they must run the same operating system version to avoid compatibility issues during SSO operations.

 A fully measured wireless survey requires tools that support the active functioning of the network and allow for physical access to install and measure equipment. A PoE (Power over Ethernet) battery is necessary to power the access point during the survey. The access point itself is essential for broadcasting the signal. A ladder is needed to reach high places for proper access point placement and to measure coverage areas effectively.

References: CCNP Enterprise Wireless Design ENWLSD 300-425 and Implementation ENWLSI 300-430 Official Cert Guide

https://www.cisco.com/c/en/us/td/docs/wireless/technology/mesh/81/design/guide/b_mesh_81/Site_Preparation_and_Planning.html

For wireless clients to use the 5 GHz band when Client Band Select is enabled, certain conditions must be met. Channel bonding should be enabled on the WLAN to allow for wider channels, providing higher throughput available in the 5 GHz band. The client must receive an RSSI above the minimum threshold set for Band Select to steer them towards the 5 GHz band. Additionally, the client device must be dual-band capable to connect to both 2.4 GHz and 5 GHz bands. Co-channel interference levels and UNII-2 extended channels being enabled offer additional benefits but are not requirements for Band Select functionality. Having 802.11a enabled on WLAN is necessary for any operation on the 5 GHz band but does not specifically relate to ensuring clients use this band under Band Select policies.

References := (CCNP Enterprise Wireless Design ENWLSD 300-425 and Implementation ENWLSI 300-430 Official Cert Guide Premium Edition and Practice)

 Cisco FastLocate technology is part of the Cisco Hyperlocation solution, which enhances location tracking accuracy and refresh rates. Implementing Cisco FastLocate technology can address issues with refresh rates for location updates in a custom mobile app by increasing the number of location data points captured, thus providing more frequent and accurate location updates.

References := AP4800 Hyperlocation Deployment Guide - Cisco

The Catalyst 9300X-48HX switches support PoE, which can power the 9166 APs. To ensure that all APs run with full functionalities, including PoE, the engineer should connect the APs to all available ports on the stack of two Catalyst 9300X-48HX switches. This will provide sufficient power and connectivity for the APs to operate effectively. References: Cisco Catalyst 9300X switch specifications and PoE requirements for 9166 APs.

The survey model described is used for location services, VoIP, data, and video. The placement of APs on exterior walls, building corners, and major turns helps ensure consistent coverage and signal strength for a variety of applications, including precise location tracking and high-quality voice and video communications. References: Designing Cisco Enterprise Wireless Networks (ENWLSD 300-425)

 The connectivity of 802.11a, which operates in the 5 GHz band, is reduced in X-ray rooms primarily due to the increased signal attenuation caused by the lead and other dense materials used in the construction of these rooms to shield against X-ray radiation. These materials effectively block or weaken the radio signals used for wireless communication

portable X-ray machines, sending high-resolution images, sometimes in real time, echography machines, and electrocardiography [ECG] machines). These devices may also use the same spectrum as Wi-Fi but with other protocols and, therefore, become sources of interference for your system.

 When configuring Cisco Prime Infrastructure, to represent the impact of a thick glass wall with an attenuation of 2dB on the RF signal, the obstacle that should be placed in the map editor is glass. This is because the material-specific attenuation values are used to model the RF signal’s behavior as it passes through different types of obstacles, and the thick glass wall’s impact is best represented by the glass obstacle in the map editor.

To support a high density of mobile devices and bond channels in groups of two, the channel width for 802.11a should be set to 40 MHz. Setting the data rates to 24 MB and Mandatory ensures that only APs can send 802.11 management frames at this rate, which helps in managing the airtime fairness. References: CCNP Enterprise Wireless Design ENWLSD 300-425 and Implementation ENWLSI 300-430 Official Cert Guide.

When identifying network requirements, it’s important to consider the number of wireless devices that will need access to ensure sufficient capacity and coverage. The business type can influence the types of applications and services that will be used, which in turn affects the network design.

When designing a wireless network for diverse clients, it’s crucial to ensure that the network will be reliable for all users. Therefore, surveys should be conducted with the client that has the worst RF characteristics, as indicated in option D. This approach ensures that the network is designed to support even the weakest client, thereby providing a consistent experience for all users.

https://documentation.meraki.com/MR/WiFi_Basics_and_Best_Practices/Conducting_Site_Surveys_with_MR_Access_Points

 Optimized roaming is a feature that helps manage the client’s roaming behavior by disassociating clients with a signal strength below a predefined threshold. This feature is designed to prevent clients from sticking to an AP with poor connectivity, which can lead to suboptimal performance. If the BSS Transition Management query is causing the client to roam and the disassociation imminent feature is not enabled, it indicates that optimized roaming is likely enabled, prompting the client to seek a better AP connection.

 For supporting hyperlocation, it is recommended that APs be aligned in the same direction. This uniform alignment helps in accurately determining the AP Azimuth, X-Y, and ceiling height information, which is crucial for hyperlocation accuracy and minimizes confusion and user-entered errors.

 In a high-availability configuration, orphaned APs will join the controller with the lowest percentage of associated Access Points (APs) per license capacity by default. This ensures a balanced distribution of APs across the controllers in the mobility group, optimizing resource utilization and network performance. References: Designing Cisco Enterprise Wireless Networks (ENWLSD 300-425)

 Metal doors cause the most signal attenuation in wireless design due to the properties of metal reflecting and absorbing radio waves, which can significantly reduce signal strength. Unlike materials such as cinder block or glass, metal can create a complete barrier for the signal, leading to a phenomenon known as “Faraday Cage” effect, where the metallic enclosure blocks electromagnetic fields. References: Designing Cisco Enterprise Wireless Networks (ENWLSD 300-425)
