220-1201 CompTIA A+ Core 1 Exam (2026) Free Practice Exam Questions (2026 Updated)

Comprehensive and Detailed Explanation From Exact Extract (Aligned With CompTIA A+ 220-1201 Study Guide)

CompTIA networking fundamentals describe VLANs (Virtual Local Area Networks) as a method to segment network traffic logically, even while using the same physical switch hardware.

A VLAN allows a company to:

Separate traffic by department

Improve security

Reduce broadcast domains

Control inter-department access

To separate accounting and customer service networks, VLANs are the industry-standard and the CompTIA-approved method.

Why the other options are incorrect

A. VPN – Used for secure remote connections, not internal LAN segmentation.

B. DNS – Resolves hostnames to IPs, not used for network separation.

D. DHCP – Assigns IP addresses; does not isolate network groups.

Final Answer: C

A bulge under the trackpad on a laptop is a strong and well-known indicator of a swollen lithium-ion battery. According to CompTIA Core 1 (220-1201) mobile device hardware and troubleshooting objectives, laptop batteries are often located directly beneath the palm rest or trackpad area. When a lithium-ion battery begins to fail, it can swell due to internal chemical reactions, causing physical deformation of nearby components.

This swelling can interfere with the normal operation of the trackpad, leading to cursor control issues, clicking problems, or unresponsive behavior. More importantly, a swollen battery presents a serious safety risk, including the potential for overheating, leakage, or fire. For this reason, CompTIA emphasizes that battery replacement should be the first corrective action when physical swelling is observed.

Replacing the trackpad would not resolve the underlying pressure caused by the expanding battery. The motherboard and heat sink are unrelated to the physical bulge and cursor control symptoms described. Proper troubleshooting requires identifying and addressing the root cause, not the secondary symptom.

CompTIA best practices also stress safe handling and immediate replacement of damaged or swollen batteries to prevent further hardware damage or personal injury.

RAID 6 is the RAID level that provides double parity, allowing the system to tolerate the failure of two disks simultaneously without data loss. According to CompTIA Core 1 (220-1201) storage and RAID objectives, RAID 6 improves fault tolerance by storing two independent parity blocks across all disks in the array.

RAID 0 provides no parity or redundancy and focuses only on performance through striping. RAID 1 uses mirroring, duplicating data across two drives but does not use parity. RAID 5 uses single parity, allowing recovery from only one failed drive.

For environments such as a local bank, where data integrity and availability are critical, RAID 6 is commonly preferred due to its higher fault tolerance compared to RAID 5. Although RAID 6 has slightly lower write performance due to the additional parity calculation, the increased resilience makes it suitable for mission-critical systems.

CompTIA highlights RAID 6 as a common enterprise solution when both redundancy and reliability are priorities.

2.4GHz Wi-Fi signals have better penetration through walls and other obstacles compared to 5GHz and 6GHz. Lower frequency waves (like 2.4GHz) travel farther and are less absorbed by physical barriers.

From the CompTIA A+ 220-1101 Official Study Guide, Objective 2.5 – Compare and contrast wireless networking protocols:

“The 2.4GHz frequency band offers greater range and better penetration through walls and obstacles than higher frequencies like 5GHz and 6GHz. Higher frequencies provide faster speeds but are more easily absorbed by walls.”

NFC (Near Field Communication) is not a Wi-Fi technology and works only over very short distances (a few centimeters).

Verified Source:

CompTIA A+ Core 1 (220-1101) Official Study Guide, Chapter 2: Wireless Networking

CompTIA Exam Objectives 220-1101, Domain 2.5

============

Comprehensive and Detailed Explanation

To enable file sharing across different operating systems, CompTIA A+ emphasizes the use of:

✔ SMB (Server Message Block)

The primary file-sharing protocol used by Windows.

Also supported on macOS and Linux (via Samba).

Allows shared folders, printers, and network browsing.

✔ FTP (File Transfer Protocol)

A cross-platform file transfer service supported by all major OSs.

Commonly used to upload/download files between systems of different types.

These two protocols are explicitly listed in CompTIA objectives under network protocols and file services.

Why the other options are incorrect

A. NTP – Time synchronization, not file sharing.

C. IMAP – Email protocol, not related to file sharing.

E. ROP – Not a file-sharing protocol (Return-Oriented Programming = security exploit).

F. LDAP – Directory service for authentication, not file sharing.

Final Answer: B, D

The Trusted Platform Module (TPM) is a hardware-based security feature used to store cryptographic keys, such as those used for encryption, authentication, or device identification. It plays a critical role in ensuring secure operations for encrypted drives, BitLocker, and secure boot processes. Clearing TPM keys involves wiping all stored cryptographic data, which can lead to several consequences depending on what the TPM was being used for. Let’s break it down:

Correct Answer: A. Encrypted hard drives would probably not be accessible.

Encrypted hard drives, such as those secured with BitLocker encryption, rely on the cryptographic keys stored in the TPM to unlock data.

Clearing the TPM will erase these keys, making it impossible for the encrypted drive to decrypt its contents unless a recovery key (separate from the TPM) is available. Without this recovery key, the data will likely become inaccessible.

CompTIA A+ Core 1 Exam Objective Reference: This falls under Objective 3.5, which covers understanding BIOS/UEFI configurations, TPM functions, and securing devices.

Why the Other Options Are Incorrect:

B. All security certificates would need to be reinstalled from trusted roots.

Clearing the TPM does not erase security certificates stored in the operating system or other areas. Certificates are generally managed by the OS or specific applications, not the TPM.Clearing the TPM only affects cryptographic keys and data stored in the TPM chip, so this is incorrect.

C. The device would need to be reenrolled in the MDM platform.

Mobile Device Management (MDM) enrollment typically does not rely on the TPM. While certain enterprise security configurations may involve the TPM, clearing it does not inherently trigger MDM reenrollment unless specifically tied to the MDM configuration.

D. The laptop would need to be registered to the domain as a new client.

While domain registrations may sometimes use TPM for authentication or secure operations, clearing the TPM alone does not require re-registering the device to the domain. The domain registration and authentication process rely more on system-level credentials than the TPM itself.

Practical Example:

A user enables BitLocker on their laptop, which relies on the TPM to store the encryption key. Later, if they clear the TPM via BIOS/UEFI without saving the BitLocker recovery key separately, they will not be able to unlock the hard drive, leading to data loss unless the recovery key is available. This is a common issue when technicians or users inadvertently clear the TPM without understanding its role in encryption.

CompTIA A+ Exam Objective Alignment:

Objective 3.5: Given a scenario, install and configure laptop hardware and components, including UEFI/BIOS security settings (TPM, secure boot, etc.).

This question tests understanding of TPM functionality, encryption technologies, and secure device configurations.

Power over Ethernet (PoE) is specifically designed to power network devices without requiring a separate electrical outlet. According to CompTIA Core 1 (220-1201) networking hardware objectives, PoE allows both data and electrical power to be delivered over a single Ethernet cable from a PoE-capable switch or injector to the connected device.

PoE is commonly used for devices such as wireless access points, IP cameras, VoIP phones, and access control systems, especially in locations where installing electrical outlets is difficult, expensive, or impractical. This makes PoE an ideal solution for flexible and scalable network deployments.

WWAN (Wireless Wide Area Network) provides cellular-based network connectivity but does not supply power to devices. An ONT (Optical Network Terminal) converts fiber signals to Ethernet and requires its own power source. NFC (Near Field Communication) is a short-range wireless technology used for authentication and data exchange, not for powering network devices.

CompTIA highlights PoE as a key networking technology that simplifies installations by reducing cabling requirements and eliminating the need for local power outlets.

A managed switch allows an administrator to enable or disable individual ports as part of network security and management. If a port on a managed switch has been disabled, the device connected to that port will lose connectivity, which matches the scenario described.

Dynamic Host Configuration Protocol (DHCP) is a network service used to automatically assign IP addresses and other network configuration details (such as subnet masks and default gateways) to devices on an enterprise-wide network.

Why Not A (DNS): DNS resolves domain names to IP addresses but does not allocate IP addresses.

Why Not B (Syslog): Syslog is used for logging system events, not IP address management.

Why Not C (Telnet): Telnet is a protocol for remote access, not for IP allocation.

CompTIA A+ Exam Reference: Core 1 (220-1201), Section 2.6, DHCP concepts​.

A smart card provides an additional factor of authentication by storing secure credentials, such as certificates, that cannot be guessed or replicated. It complements user accounts and is " something you have " .

Why Not A (Fingerprint reader): This is " something you are " , but the scenario specifically requires a physical token.

Why Not C (Secure token): Secure tokens are also valid but may not integrate as seamlessly into multi-factor authentication for physical and system access.

Why Not D (NFC scanner): An NFC scanner is a device and not a token itself; it reads cards or other credentials.

CompTIA A+ Exam Reference: Core 2 (220-1102), Section 2.5, access controls​.

DHCP normally assigns IP addresses dynamically using timed leases, meaning the address may change after expiration. However, many devices—such as servers, printers, or specialized workstations—require permanent, predictable IP addresses. CompTIA A+ identifies a DHCP reservation as the correct method for assigning a consistent IP while still using DHCP.

A reservation binds a device’s MAC address to a specific IP address in the DHCP server. Each time the device requests an address, the DHCP server recognizes the MAC address and issues the same IP. This provides reliability while still allowing centralized management of network addressing.

A lease is temporary and not permanent. An exclusion simply removes certain IP addresses from the assignable pool—it does not assign any device a fixed address. A scope option configures additional network parameters such as DNS, gateway, or WINS settings but does not assign static IPs.

Therefore, a reservation is the correct method to permanently assign an IP address using DHCP without requiring static configuration on the device itself.

The correct answer is WAN (Wide Area Network). According to CompTIA Core 1 (220-1201) networking fundamentals, a WAN is used to connect devices or networks over large geographic areas, typically through an Internet Service Provider (ISP). A WISP (Wireless Internet Service Provider) delivers internet connectivity wirelessly over long distances, which clearly falls under WAN technology.

In this scenario, the technician connects a WISP modem to a portable router to provide Ethernet connectivity to a laptop. The WISP modem represents the WAN link, as it connects the local device to an external network (the internet) managed by the service provider. The portable router then distributes that WAN connection locally via Ethernet.

A SAN (Storage Area Network) is used for high-speed storage communication between servers and storage devices and is unrelated to internet connectivity. A PAN (Personal Area Network) is limited to very short-range connections, such as Bluetooth between personal devices. A MAN (Metropolitan Area Network) covers a city or campus-scale area and is not applicable to a single modem-to-router setup.

CompTIA emphasizes identifying network types based on scope and provider involvement. Since a WISP connection extends beyond the local environment and connects to an ISP, it is classified as a WAN.

A power-redundant server typically has two power supplies so the system can continue operating if one power supply or one power feed fails. To gain the full benefit of redundancy, each PSU should be connected to independent power sources—commonly separate PDUs that are backed by different UPS units (and ideally separate circuits). This design removes a single point of failure: if one UPS

Comprehensive and Detailed 150 to 250 words of Explanation From CompTIA Core 1 Knowledge trips, fails, or is taken offline for maintenance, the other UPS still provides power and the server stays online.

Option C is best because it explicitly describes distributing the connections across different UPSs, which is the correct redundancy practice in a rack environment. Option A defeats redundancy because a single outlet/UPS failure would still bring the server down. Option B also wastes redundancy and can cause immediate downtime if the connected PSU fails, since the second PSU isn’t actively providing standby power. Option D still leaves a single UPS as the single point of failure. Therefore, splitting the two PSU power cords across separate UPS-backed outlets is the best approach.

Elasticity in cloud computing refers to the ability of a system to automatically allocate and release resources (such as CPU, RAM, or virtual machines) as workload demands change. This feature is key to ensuring that resources are used efficiently without manual intervention.

A hybrid cloud combines private infrastructure (on-premises, self-operated data centers) with public cloud services, providing flexibility and scalability.

From CompTIA A+ 220-1101 Official Study Guide, Objective 3.7 – Cloud concepts:

“A hybrid cloud model integrates private and public cloud infrastructure to allow applications and data to be shared between them.”

Verified Source:

CompTIA A+ Core 1 (220-1101) Official Study Guide, Chapter 3: Cloud Computing

CompTIA Exam Objectives 220-1101, Domain 3.7

============

When running network cable through a drop ceiling, the space above the ceiling is often used as part of the building’s air circulation system (an air return). In these plenum spaces, building and fire safety standards require cable jackets that produce less smoke and fewer toxic fumes if exposed to heat or fire. Plenum-rated cable is manufactured with a special fire-resistant jacket designed for these environments, making it the correct choice for safe and compliant cabling runs in ceilings and other air-handling areas. This is a key CompTIA A+ Core 1 concept: selecting the proper cable rating based on where the cable is installed to reduce safety hazards and meet code requirements.

The other options do not match the requirement. BNC is a connector type commonly associated with older coaxial networking and certain video applications, not a cable rating for ceiling installations. Coaxial is a cable type used for cable internet and some video signals, but the question is specifically about the required type for a drop ceiling environment, which is about the jacket rating. Fiber-optic is used for high-speed backbone links and long distances, but the question is focused on safety/installation requirements in a ceiling space. Therefore, plenum is the best answer.

Intermittent VoIP call quality issues that occur during peak hours are a classic symptom of network congestion caused by voice and data traffic competing for the same network resources. According to CompTIA Core 1 (220-1201) networking and VoIP objectives, one of the most effective solutions is to configure VLANs to separate voice and data traffic.

By placing VoIP devices on a dedicated voice VLAN, the network can apply Quality of Service (QoS) policies that prioritize voice packets over standard data traffic. This reduces latency, jitter, and packet loss, which are the primary causes of poor call quality. VLAN separation ensures that even during heavy data usage, voice traffic remains clear and reliable.

Routing calls through a gigabit port does not address traffic prioritization and is unlikely to resolve congestion during peak usage. Installing shielded network cables only helps in environments with excessive electromagnetic interference, which would affect performance consistently—not intermittently. Increasing the VoIP bit rate would actually worsen congestion by consuming more bandwidth.

CompTIA emphasizes VLAN implementation and QoS as best practices for VoIP deployments, especially when call quality degrades under high network utilization.

Gaming laptops prioritize speed, low latency, fast read/write times, and quick loading. CompTIA A+ explains that NVMe M.2 SSDs provide the fastest consumer storage available due to their use of the PCIe bus, which delivers significantly higher performance compared to SATA-based drives.

HDDs (Options A and C) are mechanical and have slow seek times, making them unsuitable for high-performance gaming. SAS SSDs (Option D) are enterprise-grade, rarely used in laptops, and require SAS controllers not found in consumer systems.

Thus, a 512GB NVMe M.2 SSD offers the best performance, fastest boot times, rapid texture loading, and optimal gaming responsiveness fully aligning with A+ hardware performance recommendations.
