In the 802.1X network access control model, the roles of the authenticator and the authentication server are distinct yet complementary. The authenticator acts as a RADIUS client, which is a network device, like a switch or wireless access point, that directly interfaces with the client machine (supplicant). The authentication server, typically a RADIUS server, is responsible for verifying the credentials provided by the supplicant through the authenticator. This setup helps in separating the duties where the authenticator enforces authentication but does not decide on the validity of the credentials, which is the role of the authentication server.

The primary reason for adding a "Log Settings" definition in the ArubaOS Diagnostics > System > Log Settings page is to configure the Syslog server settings for the server to which the Mobility Controller (MC) forwards logs for a particular category and level. This setting enables the MC to send detailed logs to a Syslog server for centralized logging and monitoring, which is essential for troubleshooting, security analysis, and compliance with various policies.

In the context of digital forensics, policy A is the most relevant. It defines which data should be logged, where logs should be forwarded for analysis or storage, and which logs should be archived for future forensic analysis or audit purposes. This ensures that evidence is preserved in a way that supports forensic activities.

EAP-TLS (Extensible Authentication Protocol - Transport Layer Security) and PEAP (Protected EAP) are two EAP methods used for 802.1X authentication in wireless networks, such as those configured with WPA3-Enterprise on HPE Aruba Networking solutions. Both methods are commonly used with ClearPass Policy Manager (CPPM) for secure authentication.

EAP-TLS:

Requires both the supplicant (client) and the server (e.g., CPPM) to present a valid certificate during authentication.

Establishes a TLS tunnel to secure the authentication process, but the primary authentication mechanism is the mutual certificate exchange. The client’s certificate is used to authenticate the client, and the server’s certificate authenticates the server.

PEAP:

Requires only the server to present a certificate to authenticate itself to the client.

Establishes a TLS tunnel to secure the authentication process, within which the client authenticates using a secondary method, typically a username and password (e.g., via MS-CHAPv2 or EAP-GTC).

Option A, "EAP-TLS begins with the establishment of a TLS tunnel, but PEAP does not use a TLS tunnel as part of its process," is incorrect. Both EAP-TLS and PEAP establish a TLS tunnel. In EAP-TLS, the TLS tunnel is used for the mutual certificate exchange, while in PEAP, the TLS tunnel protects the inner authentication (e.g., username/password).

Option B, "EAP-TLS requires the supplicant to authenticate with a certificate, but PEAP allows the supplicant to use a username and password," is correct. This is a key difference: EAP-TLS mandates certificate-based authentication for the client, while PEAP allows the client to authenticate with a username and password inside the TLS tunnel, making PEAP more flexible for environments where client certificates are not deployed.

Option C, "EAP-TLS creates a TLS tunnel for transmitting user credentials, while PEAP authenticates the server and supplicant during a TLS handshake," is incorrect. Both methods use a TLS tunnel, and both authenticate the server during the TLS handshake (using the server’s certificate). In EAP-TLS, the client’s certificate is also part of the TLS handshake, while in PEAP, the client’s credentials (username/password) are sent inside the tunnel after the handshake.

Option D, "EAP-TLS creates a TLS tunnel for transmitting user credentials securely, while PEAP protects user credentials with TKIP encryption," is incorrect. PEAP does not use TKIP (Temporal Key Integrity Protocol) for protecting credentials; TKIP is a legacy encryption method used in WPA/WPA2 for wireless data encryption, not for EAP authentication. PEAP uses the TLS tunnel to protect the inner authentication credentials.

The HPE Aruba Networking ClearPass Policy Manager 6.11 User Guide states:

"EAP-TLS requires both the supplicant and the server to present a valid certificate for mutual authentication. The supplicant authenticates using its certificate, and the process is secured within a TLS tunnel. In contrast, PEAP requires only the server to present a certificate to establish a TLS tunnel, within which the supplicant can authenticate using a username and password (e.g., via MS-CHAPv2 or EAP-GTC). This makes PEAP more suitable for environments where client certificates are not deployed." (Page 292, EAP Methods Section)

Additionally, the HPE Aruba Networking Wireless Security Guide notes:

"A key difference between EAP-TLS and PEAP is the client authentication method. EAP-TLS mandates that the client authenticate with a certificate, requiring certificate deployment on all clients. PEAP allows the client to authenticate with a username and password inside a TLS tunnel, making it easier to deploy in environments without client certificates." (Page 40, 802.1X Authentication Methods Section)

Referring to the exhibit, the ArubaOS Mobility Controller treats HTTPS packets based on the firewall rules applied to the client. The rule that allows svc-https service for destination IP range 10.1.0.0 255.255.0.0 would permit an HTTPS packet to 10.1.10.10 since this IP address falls within the specified range. There are no rules shown that would allow traffic to the IP address 203.0.13.5; hence, the packet to this address would be dropped.

ArubaOS-Switches can use sFlow technology to sample network traffic and send the samples to a collector, such as ClearPass Policy Manager (CPPM), for analysis. sFlow can be configured to capture various types of traffic, including HTTP, which typically contains User-Agent strings that can be used for device fingerprinting and classification.

To support the requirement for using HTTP User-Agent strings to classify endpoints, the switches would need to be configured to send sFlow samples containing HTTP traffic to CPPM. CPPM would then analyze these samples and use the User-Agent strings to classify the devices.

Therefore, the correct action to configure ArubaOS-Switches would involve:

Configuring CPPM as the sFlow collector on the switches.

Enabling sFlow on the edge ports that connect to endpoints.

This approach allows the network traffic to be analyzed by CPPM without requiring any additional mirroring or redirection of traffic, which would be resource-intensive and potentially disruptive to network performance.

ClearPass Policy Manager (CPPM) can receive detailed information about client device type, OS, and status from ClearPass OnGuard. ClearPass OnGuard is part of the ClearPass suite and provides posture assessment and endpoint health checks. It gathers detailed information on the status and security posture of devices trying to connect to the network, such as whether antivirus software is up to date, which operating system is running, and other details that characterize the device's compliance with the network's security policies.

Tunneling traffic between an Aruba switch and an Aruba Mobility Controller (MC) allows for the centralized application of firewall policies and deep packet inspection to wired clients. By directing traffic through the MC, network administrators can implement a consistent set of security policies across both wired and wireless segments of the network, enhancing overall network security posture.

With ArubaOS-CX switches, the use of ClearPass Policy Manager (CPPM) as a TACACS+ server for authentication is supported. The privilege levels assigned by CPPM will translate onto the switches, where the "manager" privilege level typically maps to administrative capabilities and the "operator" privilege level maps to more limited capabilities. ArubaOS-CX does support standard TACACS+ privilege levels, so administrators can be assigned appropriately. If the ClearPass policies are correctly configured, they will work for both ArubaOS-Switches and ArubaOS-CX switches. The distinction between the "administrators" and "operators" groups is inherent in the ArubaOS-CX role-based access control, and these default groups need to be appropriately mapped to the TACACS+ privilege levels assigned by CPPM.
