Choose the correct answer.

Given the following diagram:

Which diagram is correct?

A)

B)

C)

D)

A.

Option A

B.

Option B

C.

Option C

D.

Option D

Choose the correct answer.

Given the following diagram:

What do the keywords in the braces represent?

A.

suggestions for improving the efficiency of the design

B.

constraints specifying that the direction of the association is ordered and that an instance of A uniquely consists of instances of B

C.

constraints specifying that the set representing the Instances of P is ordered In the context of the association, and all instances are unique

D.

constraints specifying that all instances of B must be ordered in a unique sequence when they are associated with any instance of block A

Choose the correct answer

What is the significance of the verify relationship?

A.

The verify relationship is restricted to relating a requirement to a testCase only.

B.

The verify relationship extends the refine relationship to specify how the requirement will be verified.

C.

The verify relationship is an extension of the satisfies relationship, relating a block to a verification activity.

D.

The verify relationship relates a requirement to some other model element such as a testCase. activity, or interaction that can prove the requirement has been satisfied.

E.

The verify relationship is used to prove. That the assertion of the satisfy relationship is true Thus, a verify relationship is meaningless

without a corresponding satisfy relationship.

Choose the correct answer.

Given the following diagram:

What is the order of Interactions?

A.

Message a1 overtakes message m1, which is processed after receipt of a1.

B.

Message a1 overtakes messages m1 and m2 and is processed before them.

C.

Message m1 overtakes message a1, which is processed after receipt of m2.

D.

Message m1 overtakes messages a1 and m2 and is processed before them.

Choose the correct answer

Where may constraint blocks be defined?

A.

on any diagram

B.

only on parametric diagrams

C.

only on block definition diagrams

D.

only on block definition diagrams or package diagrams

E.

only on block definition diagrams or parametric diagrams

F.

only on block definition diagrams or internal block diagrams

Choose the correct answer.

In the following bdd, A delegates both of its ports to B:

Which ibd correctly represents this?

A)

B)

C)

D)

A.

Option A

B.

Option B

C.

Option C

D.

Option D

Choose the correct answer.

What is one key advantage of using SysML parametrics versus traditional derived properties?

A.

A derived property requires an additional constraint expression, whereas SysML parametrics does not.

B.

OCL-based constraint expressions can be used with SysML parametrics but not with derived properties

C.

it takes many more steps to specify derived properties in the typical tool compared to specifying constraint blocks.

D.

SysML parametrics supports non causal expressions, whereas a derived property involves an expression with a fixed output direction
