LEED-AP-BD+C USGBC LEED AP Building Design + Construction (LEED AP BD+C) Free Practice Exam Questions (2025 Updated)

According to the LEED v4: Building Design + Construction Guide, one of the strategies to reduce indoor water use is to optimize the consumption of showerheads by selecting fixtures that have a flow rate lower than the baseline of 2.0 gallons per minute (gpm) at 80 psi, or a local equivalent for projects outside the U.S. This can help the project achieve the Water Efficiency Prerequisite, Indoor Water Use Reduction, and the Water Efficiency Credit, Indoor Water Use Reduction, by reducing the aggregate water consumption from plumbing fixtures and fittings by at least 20% from the baseline1.

The other choices are not strategies to reduce indoor water use, because:

Designing drip irrigation for landscape is a strategy to reduce outdoor water use, not indoor water use1.

Using high-efficiency HVAC systems is a strategy to reduce energy use, not water use, although it may have some indirect water savings by reducing the cooling tower water use2.

Excluding janitor closets in the building is not a feasible or practical strategy, as janitor closets are necessary for cleaning and maintenance purposes, and may also be required by codes or standards3.

For LEED BD+C Location and Transportation (LT) Credit: Surrounding Density and Diverse Uses, Option 1: Surrounding Density, the project team must measure:

Residential density in dwelling units per acre (DU/acre) or dwelling units per hectare (DU/ha).

Non-residential density based on floor area ratio (FAR).

The density must be measured within a ¼-mile (0.40 km) radius of the project boundary.

This credit promotes high-density development and reduces urban sprawl, thereby improving access to amenities and public transportation.

(Source: Official LEED BD+C Reference Manual)

The best design approach for the office building is D. Recover waste energy through exhaust air energy recovery systems. This is because:

Installing glazing with a higher solar heat gain factor would increase the cooling load and energy consumption of the building, especially in an extremely humid climate where heat gain is high1.

Installing photovoltaic panels on the sides of the building would generate electricity from solar radiation, but it would not reduce the cooling load or energy consumption of the building, unless the electricity is used to power a heat pump or other cooling device2.

Increasing outdoor air intake quantities during summer months would provide more fresh air to dilute the indoor pollutants and improve the indoor air quality, but it would not reduce the cooling load or energy consumption of the building, unless it is combined with a ventilation system that recovers waste energy from the exhaust air stream34.

An exhaust air energy recovery system (ERV) is a type of mechanical ventilation that uses a heat exchanger to transfer heat between two streams of air: one that enters the building and one that exits. The ERV pre-cools and dehumidifies the incoming ventilation air by sending the rejected heat into the exhaust airstream to cool the condenser coil at a lower temperature. This reduces both the cooling load and energy consumption of the building, as well as improving its indoor humidity levels34. An ERV can also provide some fresh outdoor air to meet ASHRAE Standard 62 ventilation rates5.

Therefore, an ERV is a more efficient and effective design approach than glazing, photovoltaic panels, or increased outdoor air intake quantities for reducing the annual energy cost for operating an office building in an extremely humid climate and shaded by very large adjacent buildings on all four sides.

The Location and Transportation (LT) Credit: Bicycle Facilities requires short-term bicycle storage to be within 100 feet (30 meters) of a main entrance to ensure convenient access for visitors or short-term users. This credit encourages alternative transportation methods by making bicycle storage easily accessible, thereby reducing vehicular dependency. Other locations like bicycle networks or shower rooms may be relevant for long-term storage or end-of-trip facilities but are not specifically mandated for short-term storage.

Conducting a site analysis is a method to assess the regional context of a building’s design for sustainability. A site analysis involves collecting and evaluating information about the site’s location, climate, ecology, history, culture, infrastructure, regulations, and stakeholders. This can help identify the opportunities and constraints for the project, as well as the potential impacts and benefits for the environment and the community. A site analysis can inform the design decisions regarding site selection, site development, water management, energy efficiency, material selection, indoor environmental quality, and innovation12. References: LEED BD+C Reference Guide, Integrative Process, page 281; Site Analysis for Construction

The Sustainable Sites (SS) Credit for Open Space is designed to promote the integration of green building principles with outdoor physical activity. This credit encourages projects to provide outdoor spaces that are accessible and conducive to physical activities, thereby enhancing the well-being of building occupants and the surrounding community. To earn this credit, projects must provide outdoor space greater than or equal to 30% of the total site area (including building footprint). A minimum of 25% of that outdoor space must be vegetated or have overhead vegetated canopy. These spaces can be used for social interaction, passive recreation, and physical activities, aligning with the values and benefits of green building design.

The Water Efficiency Credit, Indoor Water Use Reduction aims to reduce indoor water consumption by installing water-efficient fixtures and fittings, such as faucets, showerheads, toilets, and urinals1. A commercial dishwasher that is ENERGY STAR® labeled or performance equivalent would help reduce the water use for dishwashing, which is one of the process water uses included in the credit calculation2. A standard garbage disposal would not reduce water use, but rather increase it. An electronic submeter at the domestic water supply pipe to the building would help measure and monitor water use, but not directly reduce it. An open-loop HVAC system that discharges potable cooling water to a nearby lake would waste a lot of water and potentially harm the environment.

According to the LEED v4: Building Design + Construction Guide, the owner or an owner’s representative must be a member of the integrated project team for the Integrative Process Prerequisite, Integrative Project Planning and Design. The owner or an owner’s representative is responsible for establishing the project’s vision, goals, budget, and schedule, as well as defining the owner’s project requirements (OPR) and participating in the design charrettes and reviews1. The owner or an owner’s representative also plays a key role in ensuring the continuity and alignment of the project’s performance and environmental objectives throughout all phases of the project1.

The other choices are not mandatory members of the integrated project team, although they may be involved in the integrative process depending on the project’s scope and needs. The general contractor is typically hired after the design phase and may not be involved in the predesign and schematic design analyses required by the prerequisite1. A LEED AP is a professional who has demonstrated knowledge and experience in applying the LEED rating system, but is not required to be part of the integrated project team, although it is recommended and rewarded by the LEED credit, Integrative Process1. The project’s mechanical engineer is one of the possible design consultants who may contribute to the integrative process, especially for the energy-related systems analysis, but is not required to be part of the integrated project team1.

The CIBSE Applications Manual 10 - 2005 provides detailed guidance on the use of natural ventilation as the sole servicing strategy for buildings.

It emphasizes how to design buildings with effective natural ventilation systems to reduce reliance on mechanical ventilation.

It aligns with LEED’s Indoor Environmental Quality (IEQ) strategies for improving occupant comfort and energy efficiency.

Other options are not related to this manual.

(Source: Official LEED BD+C Reference Manual)

Reducing the envelope load involves minimizing the heat that enters or escapes through a building’s envelope (walls, windows, roof, etc.). Summer solar shading is an effective strategy to block direct sunlight during warmer months, decreasing the cooling load on the HVAC system. This method helps reduce solar heat gain, which lowers energy usage for cooling. Other options like maximizing daylighting (B) increase natural light but may also increase heat gain, and decreasing the opaque wall area (C) can actually increase energy loss. Economizers (D) are HVAC strategies and don’t directly reduce the envelope load.

One of the requirements for attempting a pilot credit is to complete a feedback survey after submitting the project for review. The LEED v4 Reference Guide for Building Design and Construction states that "the project team must complete a feedback survey for each pilot credit attempted. The survey link is provided in the pilot credit language. The survey must be completed after the project has been submitted for review and before the project receives a final rating"1. The feedback survey is an important tool for USGBC to evaluate the effectiveness and applicability of the pilot credit, and to make improvements or modifications based on the project team’s experience.

The credit may be achieved by using nonroof measures only, such as shading, paving, and vegetation, to reduce the heat island effect on the site. The credit does not require a highly reflective roof for all projects, but allows for flexibility and trade-offs depending on the climate and design conditions. The project can use the Heat Island Reduction 1 to demonstrate compliance with the credit requirements. The credit is feasible and applicable for this project, and does not need an alternative compliance path. References: SS Credit Heat Island Reduction, LEED v4 Reference Guide for Building Design and Construction234

According to the LEED v4 Reference Guide for Building Design and Construction, the discovery phase of energy-related systems should identify ventilation rates, along with other factors such as building orientation, envelope attributes, lighting levels, plug and process loads, and programmatic and operational parameters1. These factors should be used to create a preliminary “simple box” energy model to evaluate the energy performance of the building and explore potential strategies to reduce energy use1. The other options are not relevant for the discovery phase of energy-related systems. Functional performance tests are part of the implementation phase1. Thermal comfort ranges are related to indoor environmental quality2. Transportation options are related to sustainable sites3. References: IP Credit Integrative Process, LEED v4 Reference Guide for Building Design and Construction4123

A preliminary water budget analysis should be conducted before schematic design is completed to integrate water efficiency strategies early in the project.

Option D is correct as early-stage planning maximizes efficiency.

(Source: Official LEED BD+C Reference Manual)

Coordinating open space features early during the site planning phase is a viable strategy for optimizing open space under Sustainable Sites Credit, Open Space. This can help to preserve natural habitats, reduce heat island effects, and enhance human health and well-being. The credit requires that the project provide outdoor space that is at least 30% of the total site area, and that at least 25% of that outdoor space meets certain criteria for vegetated, pervious, or shaded areas. References:

LEED credit library: This is the USGBC’s comprehensive listing of all the LEED credits available in pursuing certification for your project. The credit library contains the requirements and guidance for each credit, as well as the web-based reference guide for the Building Design and Construction rating system.

Open Space: This is the specific credit page for the Open Space credit under the Sustainable Sites category. It provides the intent, requirements, and strategies for achieving the credit, as well as the number of points available and the applicable project types.

Step by Step Approach to Comply with the Open Space Credit in LEED v4: This is a blog post that explains the steps and calculations involved in complying with the Open Space credit. It also provides some examples and tips for optimizing open space design.

Quality views are defined in LEED as those which consist of multiple elements of nature, weather, or movement that allow for a connection beyond the interior space. Views that allow a clear line of sight to the exterior via vision glazing, with a view factor of 3 or greater, qualify for this credit. Fixed glazing in common spaces can also contribute to this credit.

According to the LEED v4 Reference Guide for Building Design and Construction, Option 2 of the Sourcing of Raw Materials credit requires using products that meet at least one of the responsible extraction criteria for at least 25%, by cost, of the total value of permanently installed building products in the project1. Therefore, for a project with a material cost of $100,000, the minimum material value needed to achieve this option is 25% of $100,000, which is $25,000.

The rating system that is being used if all of the credits below have been submitted towards certification is Building Design and Construction: Hospitality. This is because the Location and Transportation Credit, Reduced Parking Footprint and the Indoor Environmental Quality Credit, Acoustic Performance are only available for the Hospitality rating system among the four options. The other two credits are common for all the rating systems. References: LEED v4: Building Design + Construction Guide, p. 301; LEED v4: Building Design + Construction Guide, p. 401; LEED v4: Building Design + Construction Guide, p. 411; LEED v4: Building Design + Construction Guide, p. 421

The Energy and Atmosphere Credit, Demand Response rewards projects that participate in demand response programs that aim to reduce peak electricity demand and shift the load to off-peak periods. The LEED v4 Reference Guide for Building Design and Construction states that "the intent of this credit is to increase participation in demand response technologies and programs that make energy generation and distribution systems more efficient, increase grid reliability, and reduce greenhouse gas emissions"1. The project team must either implement a permanent demand response program or develop a plan to implement a program within a year of occupancy. The project team must also demonstrate that the building has the capability to reduce its peak electricity demand by at least 10% in response to demand response signals.
