220-1101 CompTIA A+ Certification Exam: Core 1 Free Practice Exam Questions (2025 Updated)

A clicking hard drive is usually a sign of a mechanical failure, where the read/write heads are not functioning properly or the platters are scratched or broken. This can be caused by physical shock, such as dropping the laptop while it was turned on. A damaged hard drive may not be able to boot up the operating system or access the data stored on it. This is a serious problem that requires data recovery and hard drive replacement.

References

Identifying Hard Drive Sounds and Determining What They Mean

Hard Drive Clicking? See How to Fix Click Hard Drive On Your Own

Chapter 3: Hardware

Radio-frequency identification (RFID) is the most appropriate protocol to use for inventory tracking in a small warehouse. RFID is a technology that uses radio waves to identify and track objects that have RFID tags attached to them. RFID tags are small devices that store information about the object, such as its name, serial number, location, or status. RFID tags can be passive, which means they do not have a battery and rely on the radio signal from the reader to power them, or active, which means they have a battery and can transmit their own signal. RFID readers are devices that can scan the RFID tags and read the information stored on them.

RFID is suitable for inventory tracking in a small warehouse because it can provide several benefits, such as:

Faster and more accurate scanning: RFID tags can be scanned without direct line of sight, unlike barcodes, and can be scanned in bulk, unlike QR codes. This means that RFID readers can scan multiple items at once, even if they are inside boxes or containers, and reduce the time and errors involved in manual scanning.

Real-time visibility and control: RFID tags can be updated with the latest information about the inventory, such as its location, quantity, or condition. This means that RFID readers can provide real-time data and feedback on the inventory status, such as its availability, movement, or expiration. This can help improve inventory management, optimize warehouse space, and prevent stockouts or overstocking.

Enhanced security and quality: RFID tags can be encrypted and authenticated, unlike barcodes or QR codes, which can be easily copied or tampered with. This means that RFID tags can prevent unauthorized access or theft of the inventory, and ensure its authenticity and quality. This can help protect the inventory from damage, loss, or fraud, and increase customer satisfaction and trust.

A line-of-sight wireless system is a type of wireless communication that requires a clear and unobstructed path between the transmitter and the receiver. This can be achieved by using directional antennas that focus the radio signals in a narrow beam. A line-of-sight wireless system can provide a stable network connection between two buildings that are within the range and visibility of each other.

However, before purchasing and installing a line-of-sight wireless system, one of the factors that needs to be considered is the regulatory power limits. The power limit is the maximum amount of radio frequency (RF) energy that a transmitter can emit. Different countries and regions have different regulations and standards for the allowable power levels of wireless devices. Exceeding the power limit can cause interference with other wireless services, such as aviation, radio, television, etc. It can also pose health and safety risks to humans and animals.

Therefore, a technician should check the local laws and regulations for the power limits of the wireless system before buying and installing it. The technician should also use a proper tool to measure the actual power output of the transmitter and adjust it accordingly. The technician should also ensure that the transmitter and receiver are aligned properly and have a clear line of sight without any obstacles.

The other options are not relevant to the line-of-sight wireless system. The IP address range is a set of numerical identifiers that are assigned to devices on a network. It does not affect the physical transmission of wireless signals. The SSID broadcast is a feature that allows a wireless network to announce its name and availability to nearby devices. It does not affect the stability of the network connection between two buildings. The firewall rules are a set of policies that control the incoming and outgoing traffic on a network. They do not affect the line-of-sight wireless system.

A hybrid cloud model would best address the company’s needs of saving money by leveraging the cloud while still being able to customize the infrastructure. A hybrid cloud model is a combination of public and private cloud services, connected by a secure network. A public cloud service is a cloud service that is offered by a third-party provider over the Internet, and is shared by multiple customers. A private cloud service is a cloud service that is dedicated to a single customer, and is hosted either on-premises or by a third-party provider. A hybrid cloud model allows the company to use the public cloud for cost-effective and scalable services, such as storage, backup, or analytics, and use the private cloud for more sensitive or customized services, such as security, compliance, or performance. A hybrid cloud model also enables the company to move workloads between the public and private cloud as needed, depending on the demand, availability, or cost. A hybrid cloud model can provide the company with the best of both worlds: the flexibility and efficiency of the cloud, and the control and customization of the infrastructure.

The 802.11ax protocol, also known as Wi-Fi 6, provides the fastest bandwidth among the options listed. It can achieve up to 10 Gbps of data transfer rate, using technologies such as OFDMA, MU-MIMO, and 1024-QAM. The 802.11ac protocol, or Wi-Fi 5, is the second fastest, with a maximum of 3.46 Gbps, followed by the 802.11n protocol, or Wi-Fi 4, with a maximum of 600 Mbps. The 802.11a protocol is the slowest, with a maximum of 54 Mbps

https://www.lifewire.com/wireless-standards-802-11a-802-11b-g-n-and-802-11ac-816553

The correct answer is C. PoE switch.

A PoE switch is a network device that can provide both data and power to other devices over an Ethernet cable. PoE stands for Power over Ethernet, which is a technology that allows electrical power to be transmitted along with data on twisted pair Ethernet cabling. This eliminates the need for separate power supplies or AC adapters at the users’ desks, as the VoIP devices can receive power from the PoE switch12.

A firewall is a network device that monitors and controls incoming and outgoing network traffic based on predefined security rules. It does not provide power to other devices1.

A power injector is a device that adds electrical power to an Ethernet cable for a single device. It is not suitable for a large number of devices, as it would require one power injector per device1.

A router is a network device that connects multiple networks and forwards data packets between them. It does not provide power to other devices1.

Duplex printing allows printing on both sides of a paper, which can significantly reduce paper consumption and costs associated with buying paper. This makes duplex printing the best feature for cutting costs on consumables.

A firewall monitors and filters incoming and outgoing network traffic based on security rules, protecting the network from unauthorized access and threats.

Why Not A (Switch): A switch connects devices within a network but does not monitor or filter traffic.

Why Not B (Access point): An access point provides Wi-Fi connectivity but does not filter traffic.

Why Not D (Hub): A hub simply broadcasts data to all connected devices without filtering traffic.

CompTIA A+ Exam Reference: Core 1 (220-1101), Section 2.2, network security concepts​.

A loopback plug allows a technician to verify that the cable functions as expected by looping the signal back for testing. While a punchdown tool installs cables in a panel, it does not test functionality, and Wi-Fi analyzers and toner probes serve other network diagnostics. This is in line with CompTIA A+ Core 1 objectives for validating cable installation and connectivity.

After replacing a hot-swappable hard drive in a RAID 5 array, the array must rebuild the data onto the new drive. This process involves reading data from the remaining drives and writing it to the new drive to restore full redundancy. The performance decrease is due to the intensive read and write operations necessary to rebuild the RAID array, which can take several hours depending on the size of the drives and the amount of data.

The Syslog server collects logs and system messages from devices on a network. It’s a standard protocol used to store log messages from network hardware like routers, switches, and servers for diagnostics and auditing.

Option A (DNS): Translates domain names into IP addresses, not used for logging.

Option B (Mail): Manages email communication.

Option C (Print): Manages print jobs and printer sharing.

CompTIA A+ Core 1 Exam Objective Reference:

Objective 2.4: Compare and contrast common networking hardware.

Port 21 is used by FTP (File Transfer Protocol) for file transfers. Port 53 is for DNS, port 68 is for DHCP, and port 389 is for LDAP. Understanding standard network ports is essential in CompTIA A+ Core 1 objectives, especially in networking and troubleshooting scenarios.

Vertical lines on a laser printer printout are most commonly associated with issues in the drum unit. The drum is a crucial component in the laser printing process, where it receives an electrostatic image of the document to be printed and transfers toner to the paper. If there are defects or damage to the drum's surface, it can result in vertical lines appearing on the printed output as the drum fails to evenly distribute toner across the page.

RG11 coaxial cable with quad shielding is designed to handle large volumes of internet traffic, providing excellent resistance to interference and high bandwidth capacity.

Why Not A (USB 3.1): USB 3.1 is used for connecting peripherals, not for high-volume internet traffic.

Why Not C (SATA3.0): SATA is used for internal data storage connections, not for network traffic.

Why Not D (Unshielded plenum RJ45): While RJ45 cables are commonly used, unshielded cables are prone to interference and are not ideal for high-volume traffic.

CompTIA A+ Exam Reference: Core 1 (220-1101), Section 3.1, cable types and their characteristics​.

A failing power supply can cause random system crashes and degraded performance as it struggles to maintain a consistent voltage, especially as the system demands increase over time. The CMOS battery only affects system time and settings, while the video card typically causes display issues rather than system-wide crashes. System memory issues often result in specific errors or performance issues rather than gradual slowdowns. CompTIA A+ Core 1 objectives highlight troubleshooting power supply issues as part of hardware and system maintenance.

The best way to improve the efficiency of the process of formatting and reconfiguring a development PC after every application test is complete is to implement a sandbox. A sandbox is a virtual environment that isolates the application from the rest of the system, allowing the developer to test the application without affecting the main operating system, files, or settings. A sandbox can also be easily reset, deleted, or duplicated, saving the time and effort of formatting and reconfiguring the PC. A sandbox can also provide security benefits, such as preventing malware or bugs from spreading to the system or the network.

Other options, such as installing an SSD, disabling hyperthreading, or enabling hardware acceleration, may improve the performance of the PC, but they do not address the issue of formatting and reconfiguring the PC after each test. An SSD (solid state drive) is a storage device that uses flash memory instead of spinning disks, and it can offer faster data access, lower power consumption, and less noise and heat. Hyperthreading is a feature of some CPUs (central processing units) that allows each core to run two threads simultaneously, increasing the multitasking and parallel processing capabilities of the PC. Hardware acceleration is a technique that uses the GPU (graphics processing unit) or other specialized hardware to perform some tasks faster than the CPU, such as rendering graphics, video, or audio.

Explore

The correct answer is C. OLED.

OLED stands for Organic Light-Emitting Diode, and it is a type of display technology that uses organic compounds to create light and color. Unlike LCD (Liquid Crystal Display) or Plasma displays, OLED does not require a backlight or a filter to produce images. This means that OLED can offer higher contrast, wider color gamut, and better viewing angles than other display types.

LCD displays use liquid crystals that are sandwiched between two polarizing filters and illuminated by a backlight. The liquid crystals can change their orientation and block or allow light to pass through the filters. LCD displays can have different panel types, such as IPS (In-Plane Switching), VA (Vertical Alignment), or TN (Twisted Nematic), which affect the color accuracy, response time, and viewing angles of the display.

Plasma displays use gas-filled cells that are electrically charged to create plasma, which emits ultraviolet light. The ultraviolet light then excites phosphors that emit visible light and color. Plasma displays can produce deep blacks and high contrast, but they are also prone to image retention, screen burn-in, and high power consumption.

VGA stands for Video Graphics Array, and it is not a display type but a video interface standard that was introduced in 1987. VGA can transmit analog signals from a computer to a monitor, but it has low resolution and limited color depth compared to modern digital standards such as HDMI or DisplayPort.

Therefore, OLED is the best display type for graphic designers who want the most accurate color spectrum and the widest viewing angles. OLED displays can also be thinner and lighter than LCD or Plasma displays, which makes them ideal for laptops. However, OLED displays are also more expensive and less durable than other display types, and they may suffer from image retention or burn-in over time.

A printer drum is a component of a laser printer that transfers the toner to the paper. It is a cylindrical metal or plastic piece that is coated with a photosensitive material. The drum is charged by a laser beam, which creates an electrostatic image of the document to be printed. The toner then sticks to the charged areas of the drum, and the drum rolls over the paper, transferring the toner to the paper and creating the printout1.

If the printer drum is damaged, worn out, or dirty, it may not be able to transfer the toner properly, resulting in blank pages. According to some web search results23, some signs that a printer drum needs to be replaced are:

•Faint, light, faded, or blank printed pages

•Streaks, spots, or lines on the printed pages

•Error messages indicating a drum problem

To fix this issue, the technician may need to clean or replace the printer drum. Some web search results12 provide instructions on how to perform a manual drum cleaning or replacement.

Printer ink is not a likely cause of the issue, since the user has already tried installing different toners and the issue persists. Toner is the powder used by laser printers, while ink is the liquid used by inkjet printers. They are not interchangeable4.

Environmental temperature is not a likely cause of the issue, since most printers can operate in a wide range of temperatures. However, extreme temperatures may affect the quality and performance of some printers. For example, high temperatures may cause ink to dry out or toner to clump, while low temperatures may cause ink to freeze or toner to become brittle.

Corrupted printer drivers are not a likely cause of the issue, since they would affect the communication between the printer and the computer, not the printing process itself. Corrupted printer drivers may cause errors, delays, or incorrect outputs, but not blank pages.

LC stands for Lucent Connector, which is a type of fiber-optic connector that uses a push-pull mechanism to connect and disconnect the cable. LC connectors are small, compact, and widely used for high-density applications, such as data centers, servers, and networks. LC connectors have a 1.25 mm ferrule that can support both single-mode and multimode fibers.

After resolving an issue, it's crucial for a technician to document the findings, actions taken, and the outcome. This documentation serves several purposes: it provides a record of the problem and the solution for future reference, which can be helpful if the issue recurs or if similar problems arise with other users. It also ensures that any follow-up actions, if necessary, are well-informed by the history of the issue. Documenting the resolution process contributes to knowledge sharing among the support team and can improve the efficiency of future troubleshooting efforts.

The correct answer is D. Raise the filament flow amount.

Filament flow amount, also known as extrusion multiplier or flow rate, is the setting that controls how much filament is extruded by the nozzle during 3D printing. It is usually expressed as a percentage of the default value, which is 100%. Increasing the filament flow amount means extruding more filament than usual, while decreasing it means extruding less1.

The filament flow amount can affect the quality and adhesion of the first layer, which is crucial for a successful 3D print. If the filament flow amount is too low, the nozzle may not extrude enough filament to fill the gaps between the lines and create a smooth and solid first layer. This can result in poor adhesion, curling, warping, or detachment of the print from the bed12.

To improve adherence on the first layer, the user should raise the filament flow amount slightly, such as 105% or 110%, to ensure that enough filament is extruded to create a strong bond with the bed. The user should also make sure that the nozzle height, bed leveling, and bed temperature are properly calibrated for optimal first layer adhesion12.

The other options are less likely to improve adherence on the first layer, because:

•Lowering the print bed temperature may reduce the adhesion of the TPU filament to the bed, as TPU usually requires a bed temperature between 20-60°C for the best results3. Lowering the bed temperature may also increase the risk of warping or curling of the print4.

•Adjusting the RPM of the cooling fan may not have a significant effect on the first layer adhesion, as cooling fans are not required with TPU3. In fact, using a cooling fan with TPU may cause cracking or delamination of the print, as TPU needs to cool down slowly and evenly4.

•Increasing the print speed may worsen the first layer adhesion, as TPU is a flexible and elastic filament that needs to be printed slowly and consistently. A recommended print speed for TPU is 15-30mm/s3. Increasing the print speed may cause clogging, stringing, blobs, or under-extrusion of the filament4.

For more information and tips on how to 3D print TPU filament like a pro, you can visit these links:

•How to 3D Print TPU Filament Like a Pro – Ultimate Guide & FAQ

•The Complete TPU Filament 3D Printing Guide - 3DSourced

•TPU Filament 3D Printing Material – The Complete Guide

•TPU filament - learn everything about the TPU material for 3D printing

Metered utilization is a pricing model for cloud computing services, where the customer pays only for the amount of resources that are consumed, such as CPU time, memory, storage, bandwidth, etc. The customer is billed based on the actual usage of the resources, rather than a fixed or upfront fee. Metered utilization is also known as usage-based pricing or pay-per-use12.

Pay-as-you-go is an example of metered utilization, where the customer pays for the cloud resources on demand, without any long-term commitment or contract. The customer can scale up or down the resources as needed, and only pay for what is used. Pay-as-you-go is a flexible and cost-effective option for customers who have unpredictable or variable workloads, or who want to try out new services or features12.

The other options are not examples of metered utilization. Reserved instance is a pricing model where the customer pays a discounted rate for a fixed amount of cloud resources for a specified period of time, such as one or three years. The customer can reserve the resources in advance, and benefit from lower costs and guaranteed availability. Reserved instance is suitable for customers who have predictable or steady workloads, or who want to optimize their budget12.

Subscription-based is a pricing model where the customer pays a fixed fee for a set of cloud services or features for a certain period of time, such as monthly or annually. The customer can access the services or features as much as needed, without worrying about the usage or consumption of the resources. Subscription-based is suitable for customers who want to have a consistent and predictable cost, or who want to access premium or exclusive services or features12.

Multitenant is not a pricing model, but a cloud architecture where multiple customers share the same physical or virtual resources, such as servers, databases, applications, etc. The resources are isolated and secured for each customer, and the customers can benefit from lower costs, higher scalability, and faster updates. Multitenant is a common characteristic of public cloud services, where the cloud provider manages and maintains the resources for the customers12.

The correct answer is A. Enable 32-bit drivers on the Print Server.

A print server is a computer or device that manages the printing requests from multiple clients over a network. A print server can share one or more printers with different types of clients, such as Windows, Mac, or Linux. However, to ensure compatibility and functionality, the print server must have the appropriate drivers for each printer and each client1.

A driver is a software component that enables the communication and interaction between a device and an operating system. A driver must match the specifications and features of the device, as well as the architecture and version of the operating system. A driver that is incompatible with either the device or the operating system may cause errors, malfunctions, or performance issues2.

In this scenario, the technician installed a new printer that is being shared over the network via a 64-bit Windows Print Server. This means that the print server has a 64-bit operating system and a 64-bit driver for the printer. However, two users who have computers with a legacy OS (an older or outdated operating system) are unable to print to this new printer. This may be because their computers have a 32-bit operating system and require a 32-bit driver for the printer.

To resolve this issue, the technician should enable 32-bit drivers on the Print Server. This means that the technician should install and configure a 32-bit driver for the printer on the print server, in addition to the existing 64-bit driver. This way, the print server can support both 64-bit and 32-bit clients, and allow them to print to the same printer34.

To enable 32-bit drivers on a Windows Print Server, the technician can follow these steps4:

On the print server, open Control Panel and select Devices and Printers.

Right-click on the printer that needs a 32-bit driver and select Printer Properties.

Click on the Sharing tab and check the box that says Share this printer.

Click on Additional Drivers and check the box that says x86 (for 32-bit).

Click OK and follow the instructions to install and configure the 32-bit driver.

For more information about print servers, drivers, and compatibility issues, you can refer to the following web search results: What is a Print Server?, What is a Device Driver?, How to Install Additional Drivers for Shared Printers, How to Enable 32-Bit Drivers on Windows Server.

The projector is overheating and needs to be cleaned. A common cause of projector shutdown is overheating, which can be triggered by dust accumulation, blocked vents, or faulty fans. The projector has a thermal protection circuit that turns it off when the temperature reaches a certain level, and it will not turn back on until it cools down. To prevent this issue, the projector needs to be cleaned regularly and placed in a well-ventilated area. The video cable, the bulb, and the outlet are not likely to cause the projector to turn off intermittently.

The correct answer is A. Serial.

A serial cable is a type of cable that can be used to connect a laptop to a network device via a serial port. A serial port is a physical interface that allows data transmission between devices using serial communication, which is a method of sending data one bit at a time over a single wire. Serial ports are often used for console access to network devices, such as routers, switches, firewalls, or servers, when other methods of connection, such as SSH (Secure Shell), are not available or not working.

SSH is a protocol that allows secure and encrypted remote login and command execution over a network. SSH uses public key cryptography to authenticate the client and the server, and to encrypt the data exchanged between them. SSH can be accessed through different ports, depending on the configuration of the server and the client. The default port for SSH is 22, but it can be changed to any other port for security reasons.

HDMI (High-Definition Multimedia Interface) is a type of cable that can be used to transmit audio and video signals between devices, such as laptops, monitors, TVs, or projectors. HDMI cables support high-definition video and audio formats, and can also carry Ethernet and power signals. HDMI cables are not suitable for connecting to network devices via SSH, as they are designed for multimedia purposes.

Parallel cables are a type of cable that can be used to connect devices that use parallel communication, which is a method of sending data multiple bits at a time over multiple wires. Parallel cables are often used for connecting printers or scanners to computers, but they are not commonly used for network devices or SSH connections.

Lightning cables are a type of cable that can be used to connect Apple devices, such as iPhones, iPads, or iPods, to computers or chargers. Lightning cables support data transfer and power delivery, and can also be used with adapters to connect to other types of ports, such as USB or HDMI. Lightning cables are not compatible with network devices or SSH connections, as they are specific to Apple products.

Therefore, the only cable that can be used as an alternative connection method with a laptop when SSH is not working is a serial cable. Serial cables can provide console access to network devices and allow configuration and troubleshooting commands to be executed. For more information about SSH and its alternatives, you can refer to the following web search results: Alternatives to SSH, How To Configure Custom Connection Options for your SSH Client, Understanding the SSH Encryption and Connection Process, How to Use Public Key Authentication with SSH.

The best way to complete the upgrade with the least amount of downtime is to clone the HDD to the SSD using cloning software, and then replace the HDD with the SSD. This way, the user does not have to reinstall the operating system and applications, or copy over their data manually. The other options would either take more time or result in data loss or inaccessibility. Verified References: [How to Upgrade Your Laptop’s Hard Drive to an SSD].

The most important specification that the technician should verify before installing the new power supply is A. The wattage.

The wattage of a power supply is the measure of how much power it can deliver to the components of a computer. The wattage of a power supply should match or exceed the total power consumption of the computer, otherwise the computer may not function properly or may experience instability, overheating, or damage12.

To calculate the total power consumption of a computer, the technician can use a tool such as a power supply calculator, which can estimate the required wattage based on the components and features of the computer. For example, using one of the web search results3, I entered the following information:

•CPU: 3 GHz processor

•GPU: High-end graphics card

•RAM: 16 GB DDR4

•SSD: 1 x 500 GB

•HDD: 1 x 1 TB

•Optical Drive: 1 x DVD-RW

•Fans: 2 x 120 mm

•Other Devices: Keyboard, Mouse, Monitor

The tool estimated that the recommended PSU wattage for this computer is 550 W. Therefore, the technician should verify that the new power supply has at least this wattage before installing it.

The chassis ventilation, the motherboard’s firmware, and the cables’ color coding are not as important as the wattage for installing a new power supply. The chassis ventilation is related to the airflow and cooling of the computer, which can affect the performance and lifespan of the components. The motherboard’s firmware is the software that controls the basic functions of the motherboard, such as booting, input/output, and memory management. The cables’ color coding is a standard way of identifying the function and polarity of the wires in a power supply. However, none of these specifications are directly related to the power delivery or compatibility of the new power supply.

A digitizer is a component that converts the touch input on a tablet screen into digital signals that can be processed by the device. A digitizer consists of a thin layer of transparent material that covers the glass screen and has sensors that detect the position and pressure of the touch. If the digitizer is damaged, misaligned, or poorly calibrated, it can cause inaccurate touch input, such as selecting the wrong item or not responding at all12. Therefore, the most likely cause of the issue in this scenario is a faulty digitizer that may need to be replaced. The other components are not directly related to the touch input functionality of the tablet. A gyroscope is a sensor that measures the orientation and rotation of the device3. A battery is a power source that supplies electricity to the device4. A glass is a protective layer that covers the screen and prevents scratches and cracks5.

References

1: What is a Digitizer? - Definition from Techopedia

2: How to Fix a Broken Digitizer on a Tablet | Chron.com

3: What is a Gyroscope Sensor in Mobile Phones? - Definition from Techopedia

4: What is a Battery? - Definition from Techopedia

5: What is Glass? - Definition from Techopedia

The most likely cause of the failure is A. Thermal paste was not used.

Thermal paste, also known as thermal grease or thermal compound, is a substance that is applied between the CPU and the heat sink to improve the heat transfer and cooling of the CPU. Thermal paste fills the gaps and irregularities between the CPU and the heat sink, creating a better contact and reducing the thermal resistance .

According to some web search results , some signs and symptoms of not using thermal paste or using it incorrectly are:

•The CPU overheats and slows down or shuts down to prevent damage

•The CPU fan spins faster and louder to try to cool down the CPU

•The PC performance drops or becomes unstable

•The PC crashes or displays errors or blue screens

To fix this issue, the technician should apply thermal paste properly between the CPU and the heat sink, following these steps :

•Turn off the PC and unplug it from the power source

•Open the PC case and locate the CPU fan and heat sink

•Remove the CPU fan and heat sink from the motherboard

•Clean the surfaces of the CPU and heat sink with a lint-free cloth and alcohol

•Apply a small amount of thermal paste (about the size of a grain of rice) in the center of the CPU

•Reattach the heat sink and CPU fan to the motherboard, making sure they are aligned and secured

•Close the PC case and plug it back to the power source

The GPU needs additional power, the memory is insufficient, or the motherboard is incompatible are not likely causes of the failure, since they would not cause the PC to overheat and shut down after a few minutes. The GPU needs additional power if it has a high power consumption that exceeds the capacity of the power supply or the PCIe slot. The memory is insufficient if it cannot handle the applications or tasks that are running on the PC. The motherboard is incompatible if it does not support the CPU, RAM, or other components that are installed on it. These issues may cause poor performance, errors, or crashes, but not overheating and shutting down.

A wireless adapter is a device that allows a laptop to connect to a wireless network, such as a home Wi-Fi router. A wireless adapter can be either internal or external, and it can be enabled or disabled by the user or the operating system. If the wireless adapter is disabled, the laptop will not be able to access the internet when it is not connected to a wired network, such as the office dock.

The technician should do the following steps to enable the wireless adapter:

Check the physical switch or button on the laptop that controls the wireless adapter. Some laptops have a switch or button on the side, front, or keyboard that can turn on or off the wireless adapter. Make sure the switch or button is in the on position.

Check the software settings for the wireless adapter. In Windows 10, you can do this by clicking on the network icon in the system tray, and then clicking on the Wi-Fi icon. Make sure the Wi-Fi is turned on. You can also go to Settings > Network & Internet > Wi-Fi and make sure the Wi-Fi is turned on.

Check the device manager for the wireless adapter. In Windows 10, you can do this by right-clicking on the Start menu and selecting Device Manager. Expand the Network adapters category and look for your wireless adapter. Make sure it is enabled and has no errors. You can right-click on it and select Enable device or Update driver if needed.

If none of these steps work, there may be a hardware or software problem with the wireless adapter that requires further troubleshooting or replacement.

A load balancer is a device or software that distributes network traffic across multiple servers or resources, such as web server farms, to optimize performance, reliability, and scalability. A load balancer controls the flow of users connecting to web server farms and prevents overutilization on any individual server by using various algorithms, such as round robin, least connections, or weighted distribution. A load balancer can also provide health checks, failover, caching, compression, encryption, and other features to enhance the user experience and security.

The correct answer is D. PAN.

A PAN, or Personal Area Network, is a type of network that connects devices within a short range, usually less than 10 meters, and is used by an individual. A PAN can be wireless or wired, and it can enable data transmission between devices without requiring an internet connection. A PAN can also be connected to a LAN or a higher level network, where one device acts as a gateway.

A Bluetooth hotspot is an example of a wireless PAN, where a device such as a smartphone or a laptop can create a network with other Bluetooth-enabled devices nearby. A Bluetooth hotspot can allow devices to share files, access the internet, or use peripherals such as printers or speakers.

A SAN, or Storage Area Network, is a type of network that connects storage devices such as hard disks, tape drives, or optical drives to servers. A SAN provides high-speed data transfer and access to large amounts of data. A SAN is usually used in data centers or enterprises that need to store and manage huge volumes of data.

A WAN, or Wide Area Network, is a type of network that connects devices over a large geographical area, such as across cities, countries, or continents. A WAN can use different technologies and media to transmit data, such as fiber-optic cables, satellite links, or radio waves. A WAN can also consist of multiple LANs or other types of networks. The internet is the largest example of a WAN.

A LAN, or Local Area Network, is a type of network that connects devices within a limited area, such as within a building or a campus. A LAN can use wired or wireless technologies to transmit data, such as Ethernet cables, Wi-Fi routers, or switches. A LAN can enable devices to share resources, such as printers, scanners, or files.

For more information about the types of networks and their differences, you can refer to the following web search results: 11 Types of Networks: Understanding the Differences, Types of Computer Networks, Types of network - Introduction to networks.

MMS (Multimedia Messaging Service) is a type of text message that can include images, videos, audio, or other media files. Unlike SMS (Short Message Service), which only uses cellular networks, MMS requires mobile data service to send and receive messages. Therefore, if the mobile data service is disabled on the smartphone, the user will not be able to send or receive MMS messages, even if they can make and receive voice calls using the cellular network.

References

•What is MMS messaging? How to send and receive MMS messages on your iPhone or Android device

•Why Can’t I Send or Receive MMS Messages?

•The Official CompTIA A+ Core 1 Student Guide (Exam 220-1101), page 349

A thermal receipt printer uses heat to print on thermal paper, which has a special coating that reacts to heat and produces black marks. If the paper roll is inserted in the wrong orientation, the printer will not be able to print anything on the paper. Therefore, the first thing the technician should do is to check if the paper roll is loaded correctly, with the paper feeding under, not over. This is a common and easy mistake to fix, and it does not require any software or hardware changes.

References

•Troubleshooting Your Thermal Printer Problems - Thermal POS Receipt Printer Tips & Tricks, paragraph 2

•POS Thermal Receipt Printer Troubleshoot - Not Printing Evenly, video at 0:15

•Receipt Printer Troubleshooting – Shopfront, bullet point 2

When troubleshooting a thermal receipt printer that fails to print, the CompTIA A+ Core 1 Study Guide advocates starting with the simplest, most common, and least invasive steps before escalating to more complex solutions. Thermal printers rely on heat-sensitive paper, and a frequent issue is incorrect paper orientation—thermal paper has a coated side that must face the printhead to produce an image. If the paper roll is installed upside down, the printer won’t print, as the heat from the thermal head won’t interact with the correct side of the paper. This is a quick fix that doesn’t require tools or software changes, aligning with CompTIA’s troubleshooting methodology (Objective 5.6: "Given a scenario, troubleshoot and resolve printer issues").

D. Flip the paper roll orientation: Checking and correcting the paper orientation is a basic, immediate step that addresses a common thermal printer issue. It’s non-disruptive and aligns with initial troubleshooting principles.

A. Update the printer driver: Driver issues could prevent printing, but this assumes a software problem without evidence and isn’t the first step when hardware basics haven’t been checked.

B. Replace the thermal printhead: A failed printhead could cause non-printing, but replacing hardware is a later step after ruling out simpler causes, as it’s costly and invasive.

C. Make sure the thermal head is heating up: Verifying the printhead’s functionality is a valid diagnostic step, but it requires tools (e.g., checking heat output) and assumes a hardware failure, making it less immediate than checking paper orientation.

The study guide emphasizes starting with physical checks—like paper installation—before moving to software or hardware diagnostics, making flipping the paper roll the most logical first action.

Exact Extracts from the Study Guide:

From The Official CompTIA A+ Core 1 Study Guide (220-1101):

Section 3.7, Printer Consumables:

"Thermal Printers: Thermal printers use heat to create an image on specially coated paper… The paper must be loaded correctly, with the coated side facing the thermal printhead, or no image will be produced. If the printer is not printing, check the paper orientation first."

Implication: Incorrect paper orientation is a primary cause of printing failure in thermal printers.

Section 5.6, Troubleshooting Printer Issues:

"Printer will not print—Verify that the printer is powered on and online… Check that the paper is loaded correctly (for thermal printers, ensure the coated side faces the printhead). Next, check for paper jams, then verify connectivity and driver settings."

"Troubleshooting methodology: Identify the problem… Test the simplest solutions first (e.g., paper loading, power, cables) before escalating to software or hardware replacement."

These excerpts confirm that checking paper orientation is the initial step for thermal printer issues, as it’s a frequent user error and easily corrected.

Additional Reasoning:

Thermal Printer Mechanics: Thermal receipt printers don’t use ink or toner; they heat the paper directly. If the non-coated side faces the printhead, no output occurs, making orientation a top troubleshooting priority.

Symptom Specificity: The printer “will not print” suggests no output at all, not faded or partial printing (which might point to a printhead or driver issue). Paper orientation fits this symptom perfectly.

CompTIA Approach: The methodology prioritizes quick, low-cost checks (paper, power, connections) over software updates or hardware swaps, especially in a SOHO or retail environment where receipt printers are common.

Other Options:

Driver Update (A): Relevant if the printer is online but not responding to print jobs, not the first step without connectivity clues.

Replace Printhead (B): Premature without testing the existing head’s functionality.

Check Heating (C): Useful but requires diagnostic effort (e.g., test page or thermal test), making it a follow-up step.

High availability is a characteristic of cloud computing that prioritizes reliability. High availability means that cloud services can be accessed without interruption or failure, even in the event of a disaster or a hardware malfunction. This is achieved by using redundant components, backup systems, load balancing, and failover mechanisms. According to the CompTIA Core1 objectives, one of the benefits of cloud computing is high availability. A research paper on cloud reliability also defines high availability as the ability to provide continuous service despite faults or failures.

The correct answer is A. Examine the application and device mute controls.

One of the possible reasons for the USB headset microphone not working is that the microphone is muted in the application or device settings. The technician should check if the mute button on the headset or the microphone icon in the application is active. If so, the technician should disable them and try to record sound again.

Some applications may also have their own settings for the microphone input. The technician should make sure that the USB headset is selected as the input device and that the volume level is appropriate. The technician can also test the microphone in different applications to see if the problem is specific to one application or not.

The other options are less likely to solve the problem, because:

•Connecting the headset to a different USB port may not make any difference if the device is already installed and recognized by the system.

•Checking the device’s driver release date may not be relevant if the microphone was working before and no updates were installed recently.

•Increasing the speaker volume setting may not affect the microphone input at all, and may only make the audio playback louder.

For more information and tips on how to fix USB headset problems, you can visit these links:

•USB Headset Mic Not Working? Here Are All Possible Fixes - TechNorms

•Fix microphone problems - Microsoft Support

•USB Headset Not Working? Try These Fixes - Tech News Today

A burning smell on a desktop computer is a serious issue that indicates a hardware malfunction or failure. It can be caused by overheating, a faulty power supply, a malfunctioning motherboard, or a short circuit12. If left unchecked, it can damage the components, cause a fire, or harm the user.

The first thing the technician should do when troubleshooting a burning smell on a desktop computer is to unplug the computer from the power source. This will stop the flow of electricity and prevent further damage or fire. The technician should also wear protective gloves and eye wear to avoid contact with any hot or hazardous parts.

The other options are less likely to be the first step in troubleshooting, because:

•Locating a fire extinguisher is a good precaution, but it should not be done before unplugging the computer. The fire extinguisher should only be used if there is visible smoke or flames coming from the computer, and only after unplugging it and ensuring that it is safe to do so.

•Calling the fire department is an extreme measure that should only be done if there is an actual fire that cannot be controlled by the fire extinguisher. It should not be done before unplugging the computer and trying to identify and fix the problem.

•Removing the desktop cover is a necessary step to inspect the internal components and find the source of the burning smell. However, it should not be done before unplugging the computer, as it can expose the technician to live wires and electric shocks.

For more information and tips on how to troubleshoot a burning smell on a desktop computer, you can visit these links:

•How to find the source of a burning smell in my computer?

•Burning Smell From PC? 10 Reasons Why It Could Happen

To enable the printer to be shared across the network, the technician should configure the IP settings of the printer. The IP settings include the IP address, subnet mask, default gateway, and DNS server of the printer. The IP settings allow the printer to communicate with other devices on the network and access network resources such as print servers or cloud services.

The technician can configure the IP settings of the printer in different ways, such as:

Using the printer’s control panel or web interface to manually enter the IP settings or obtain them automatically from a DHCP server.

Using the printer’s software or driver to assign a static or dynamic IP address to the printer.

Using a network discovery tool to find and configure the printer on the network.

The technician should also make sure that the IP settings of the printer are compatible with the network configuration and do not cause any conflicts or errors.
