Comprehensive and Detailed Explanation From FortiOS 7.6, FortiWeb 7.4 Exact Extract study guide:

According to the FortiOS 7.6 Azure Administration Guide and the Fortinet 7.4 Public Cloud Security documentation regarding Azure Virtual WAN (vWAN) architectures, the choice of connectivity depends on the required performance, security, and scale:

ExpressRoute (Option D): For a large-scale enterprise deployment involving a company headquarters and multiple branch sites, ExpressRoute is the "best" and most robust solution. It provides a private, dedicated, and high-throughput connection (up to 100 Gbps) that bypasses the public internet entirely. This ensures predictable low latency and higher reliability compared to internet-based tunnels.

Virtual WAN Integration: Azure vWAN Standard SKU explicitly supports ExpressRoute gateways as a primary connectivity method for on-premises sites. This allows the vWAN hub to act as a global transit point, seamlessly connecting the ExpressRoute-linked headquarters to other branch sites and VNET spokes.

Scalability for Headquarters: While site-to-site IPsec VPNs are common for smaller branches, the "main company site" or headquarters typically requires the high bandwidth and SLA guarantees provided by ExpressRoute.

Why other options are incorrect:

Option A & B: L2TP and SSL VPN are primarily used for remote user access (Point-to-Site) rather than permanent site-to-hub infrastructure connections. vWAN uses OpenVPN or IKEv2 for user VPNs, not L2TP.

Option C: While GRE tunnels are used in some networking scenarios, they are not a native, primary gateway connectivity option for the Azure vWAN hub compared to the standardized Site-to-Site VPN (IPsec) and ExpressRoute.

According to the FortiOS 7.6 Azure Administration Guide and the Cloud Security 7.4 Public Cloud Study Guide, the integration of FortiGate-VMs with an Azure Gateway Load Balancer (GWLB) requires specific network configurations to ensure packet transit:

IP Forwarding Requirement (Option A): By default, Azure Network Interfaces (NICs) drop any traffic that does not originate from or is not destined for the IP address assigned to that NIC. For a FortiGate to act as a "bump-in-the-wire" or transparent inspector, it must receive traffic destined for other IPs and forward it. This requires the IP Forwarding setting to be explicitly enabled on the FortiGate's network interfaces within the Azure portal. If this is disabled, the Azure fabric will discard the traffic being steered through the FortiGate HA cluster by the GWLB.

VXLAN Encapsulation: The Azure GWLB uses VXLAN to encapsulate traffic (adding a VXLAN header with a specific VNI) before sending it to the FortiGate. The FortiGate must terminate this VXLAN tunnel. While the VXLAN configuration is crucial, the underlying infrastructure check for IP Forwarding is the most common cause of traffic being blocked at the NIC level before the FortiOS stack can process the packet.

Why other options are incorrect:

Option B: If health probes fail, the GWLB will typically stop sending traffic to that specific instance. While this affects the HA cluster's availability, the question states traffic is not being routed correctly through the firewalls (implying an active flow issue), and the primary mechanism for allowing a VM to process third-party traffic in Azure is IP Forwarding.

Option C: NSGs are typically applied to the NIC or Subnet. While incorrect NSG rules can block traffic, "IP Forwarding" is a specific requirement for the FortiGate to function as a network appliance (NVA) regardless of the NSG state.

Option D: Azure GWLB supports cross-subscription and cross-tenant chaining. The consumer (protected VMs) and the provider (FortiGate HA cluster) do not need to be in the same subscription, provided the GWLB endpoint is correctly mapped.
